  • Page 1 User Manual PCM-37D24DI 24-ch Isolated Digital I/O, M.2 B+M key (3042, PCIe*1), DB37...
  • Page 2: Product Warranty (2 Years)

    No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 4: Document Feedback

    Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: support@advantech. Packing List Before setting up the system, check that the items listed below are included and in good condition.
  • Page 5: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 Don't touch any components on the CPU card or other cards while the PC is on.  Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. PCM-37D24DI User Manual...
  • Page 7: Table Of Contents

    Signal connections .................. 13 3.3.1 Pin Assignment ................13 Figure 3.2 Isolated DI Connection ..........14 Figure 3.3 Isolated Digital Output Connection ......14 Appendix A Specifications ........15 Specifications ..................16 Appendix B Block Diagram ........17 Block Diagram..................18 PCM-37D24DI User Manual...
  • Page 8 PCM-37D24DI User Manual viii...
  • Page 9: Chapter 1 Introduction

    Chapter Introduction This chapter provides a general description of the PCM-37D24DI. Sections include:  Description  Features  Applications  Installation Guide  Software Overview  Accessories...
  • Page 10: Description

    Plug-and-Play function. Board ID The PCM-37D24DI has a built-in DIP Switch that helps define each card’s ID when multiple PCM-27D24DI cards have been installed on the same PC chassis. The board ID setting function is very useful when users build their system with multiple PCM-37D24DI cards.
  • Page 11 Frequency measurement: PCM-27D24DI built-in counter can measure the fre- quency value of the signal connected to counter input. Pulse Width measurement: PCM-27D24DI built-in counter can measure the pulse width value of the signal connected to counter input. PCM-37D24DI User Manual...
  • Page 12: Applications

    Software Overview Advantech offers device drivers, SDKs, third-party driver support and application software to help fully exploit the functions of your PCM-37D24DI card. All these soft- ware packages are available on the Advantech website to get the latest update: http://www.advantech.com/.
  • Page 13: Accessories

    Accessories Advantech offers a complete set of accessory products to support the PCM-37D24DI card. These accessories include: Wiring Cable The PCL-10137 shielded cable is specially designed for PCM-37D24DI cards to pro- vide high resistance to noise. To achieve better signal quality, the signal wires are twisted in such a way as to form a “twisted-pair cable”, reducing cross-talk and noise...
  • Page 14 PCM-37D24DI User Manual...
  • Page 15: Chapter 2 Hardware Installation

    Chapter Hardware Installation  Installation  Unpacking  Driver Installation  Hardware Installation...
  • Page 16: Installation

    PC or transport it elsewhere. Driver Installation We recommend you to install the driver before you install the PCM-37D24DI card into your system, since this will guarantee a smooth installation process. The Advantech device driver installation for the PCM-27D24DI card is included on the companion CD-ROM that is shipped with your DA&C card package, or you can...
  • Page 17: Hardware Installation

    Win95/98/ME will recognize your card as an “unknown device” after rebooting, and will prompt you to provide the necessary driver. Ignore the prompting messages (just click the Cancel button) and set up the driver according to the steps described in 2.3 Driver Installation. PCM-37D24DI User Manual...
  • Page 18 After the PCM-37D24DI card is installed, you can verify whether it is properly installed on your system through the Device Manager: Access the Device Manager through Control Panel/System/Device Manager. The device name of the PCM-27D24DI should be listed on the Device Manager tab as follows.
  • Page 19: Chapter 3 Signal Connections

    Chapter Signal Connections  Overview  Switch and Jumper Settings  Signal Connections...
  • Page 20: Overview

    PCM-27D24DI via the I/O connector. Switch and Jumper Settings Figure 3.1 Card Connector, Jumper and Switches Table 3.1: Summary of Jumper Settings Jumper Name Function Description Load default while reset (default) Keeps the last status after reset (enabled) PCM-37D24DI User Manual...
  • Page 21: Signal Connections

    Isolated digital output ECOM0: External common of IDI0~7 ECOM1: External common of IDI8~15 PCOM: Free wheeling common diode for IDO EGND: External ground GATEn (n=0 ~ 1): Counter n gate input CLKn (n=0~1): Counter n clock input Not Connected PCM-37D24DI User Manual...
  • Page 22 Internal External Diode PCOM Common IDO0 IDO1 Isolated IDO2 Relay Circuit IDO3 IDO4 IDO5 IDO6 5~40V IDO7 EGND Figure 3.3 Isolated Digital Output Connection PCM-37D24DI User Manual...
  • Page 23 Appendix Specifications...
  • Page 24: Appendix A Specifications

    51 x 30 x 12.4mm I/O Plate 81 x 19.4 x 41mm Power Consumption Typical +3.3V @ 400 mA +3.3V @ 520 mA Temperature Operation -20~60 C(-4~140 Storage -40~85 C(-40~185 Relative Humidity 5~90%RH non-condensing Certification CE certified PCM-37D24DI User Manual...
  • Page 25: Appendix B Block Diagram

    Appendix Block Diagram...
  • Page 26: Block Diagram

    Block Diagram PCM-37D24DI User Manual...
  • Page 27 PCM-37D24DI User Manual...
  • Page 28 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2013...
