Summary of Contents for Advantech PCIE-1756H
- Page 1 User Manual PCIE-1756H 64-ch Isolated Digital I/O with Digital Filter PCI Express Card...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 Don't touch any internal components, the CPU, or any adapter cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. PCIE-1756H User Manual...
-
Page 5: Table Of Contents
Figure 3.6 Wiring in dry contact input mode ......20 Field Wiring Considerations ..............20 Appendix A Specifications ........21 Isolated Digital Input................22 Digital Filter Time ..................22 Isolated Digital Output................22 General ....................23 Appendix B Block Diagrams .........25 PCIE-1756H User Manual... - Page 6 Block Diagrams..................26 Appendix C ADAM-3951 Pin Assignment.... 27 ADAM-3951 Pin Assignment ..............28 Figure C.1 Connect to PCL-10250 CON1........28 Figure C.2 Connect to PCL-10250 CON2........29 PCIE-1756H User Manual...
- Page 7 Chapter Introduction This chapter introduces the PCIE- 1756H cards and their typical applications. Sections include: Features Applications Installation Guide Software Overview Device Driver Roadmap Accessories...
-
Page 8: Chapter 1 Introduction
The PCIE-1756H can durably withstand a voltage up to 2,500 VDC, preventing your host system from harm. Wide Input Range The PCIE-1756H accepts a wide range of input voltage, from 10 to 30 V , and it is suitable for most industrial applications with 12 V and 24 V input voltage. -
Page 9: Applications
Board ID Setting The PCIE-1756H has a built-in DIP switch that defines each card’s ID when multiple cards have been installed in the same PC chassis. The board ID setting function is very useful when users build systems with multiple PCIE-1756H cards. With correct Board ID settings, you can easily identify and access each card during hardware con- figuration and software programming. -
Page 10: Installation Guide
Installation Guide Before you install your PCIE-1756H card, please make sure you have the following necessary components: PCIE-1756H DAQ Card PCIE-1756H Startup or User Manual Driver Software Advantech DAQNavi software (included in DVDROM) Wiring Cable PCL-10250 or PCL-101100M (optional) ... -
Page 11: Software Overview
Software Overview Advantech offers a rich set of DLL drivers, third-party driver support and application software to help fully exploit the functions of your PCIE-1756H card: DAQNavi software (on the companion DVD-ROM) LabView driver Advantech DAQ tools Programming choices for DA&C cards... -
Page 12: Daqnavi Device Driver Programming Roadmap
1.6.2 Programming with DAQNavi Device Drivers Function Library Advantech DAQNavi device drivers offer a rich function library that can be utilized in various application programs. This function library consists of numerous APIs that support many development tools, such as Visual Studio .Net, Visual C++, Visual Basic and Borland Delphi. -
Page 13: Accessories
Wiring Cables PCL-10250 The PCL-10250 is a 100-pin SCSI to two 50-pin SCSI shielded cables that is specially designed for the PCIE-1756H card. It should be used with the ADAM-3951 wiring board. PCL-101100M The PCL-101100M cable is a 100pin SCSI shielded cable. It can be used with ADAM-39100 wiring board. - Page 14 PCIE-1756H User Manual...
-
Page 15: Chapter 2 Installation
Chapter Installation This chapter provides a packaged item checklist, proper instructions for unpacking and step-by-step procedures for both driver and card installation. Sections include: Unpacking Driver Installation Hardware Installation Device Setup & Configuration... -
Page 16: Unpacking
PC or transport it elsewhere. Driver Installation We recommend you install the driver before you install the PCIE-1756H card into your system, since this will guarantee a smooth installation process. The Advantech DAQNavi Device Drivers Setup program for the PCIE-1756H card is included in the companion DVD-ROM that is shipped with your DA&C card package. -
Page 17: Hardware Installation
Touch the metal part on the surface of your computer to neutralize the static electricity that might be on your body. Insert the PCIE-1756H card into a PCI slot. Hold the card only by its edges and carefully align it with the slot. Insert the card firmly into place. Use of excessive force must be avoided;... - Page 18 PCIE-1756H User Manual...
-
Page 19: Chapter 3 Signal Connections
Chapter Signal Connections This chapter provides useful information about how to connect input and output signals to the PCIE-1756H cards via the I/O con- nector. Sections include: Overview Switch and Jumper Settings Signal Connections Field Wiring Considerations... -
Page 20: Overview
This chapter provides useful information about how to connect input and output signals to the PCIE-1756H cards via the I/O connector. Switch and Jumper Settings Please refer to Figure 3.1 for jumper and switch locations on PCIE-1756H. Figure 3.1 Connector and Switch Locations PCIE-1756H User Manual... -
Page 21: Board Id (Sw1)
3.2.1 Board ID (SW1) The PCIE-1756H has a built-in DIP switch (SW1), which is used to define each card’s board ID. When there are multiple cards in the same chassis, this board ID switch is useful for identifying each card’s device number. After setting for each PCIE-1756H, you can identify each card in the system with a different device number. -
Page 22: Power On Configuration(Jp1)
3.2.3 Channel-Freeze Function (JP2) The PCIE-1756H provides the channel-freeze function for isolated digital output channels. When Channel-Freeze function is enabled, all ports on the card will be locked so that the data transmitted (from the host PC) to the card won’t be trans- ferred to the DO ports. -
Page 23: Signal Connections
Signal Connections Pin Assignment The I/O connector on the PCIE-1756H is a 100-pin connector that enable you to con- nect to accessories with the PCL-10250 or PCL-101100M shielded cable. Figure 3.2 shows the pin assignments for the 100-pin I/O connector on the PCIE- 1756H, and Table 3.4 shows the I/O connector signal description. -
Page 24: I/O Connector Pin Definition
Meaning that you can apply positive or negative voltage to an isolated input pin (V ). Every 16 input channels share one common pin. Figure 3.3 shows how to connect an external input source to one of the card’s isolated input channels. Figure 3.3 Isolated Digital Input Connection PCIE-1756H User Manual... -
Page 25: Isolated Digital Output
Figure 3.4 Isolated Digital Output Connection 3.3.4 Channel-Freeze Function The PCIE-1756H provides a digital input channel (CH_FRZ_IN) to enable the chan- nel-freeze function. The channel-freeze function acts when the pin CH_FRZ_IN is activated. Moreover, you can set up the input mode of channel-freeze function input channel CH_FRZ_IN as dry contact input mode or wet contact input mode selected by on-board jumper JP2. -
Page 26: Field Wiring Considerations
Figure 3.6 Wiring in dry contact input mode Field Wiring Considerations When you use PCIE-1756H cards to acquire data from outside, noises in the environ- ment might significantly affect the accuracy of your measurements if due cautions are not taken. The following measures will be helpful to reduce possible interference run- ning signal wires between signal sources and the PCIE-1756H card. -
Page 27: Appendix A Specifications
Appendix Specifications... -
Page 28: Isolated Digital Input
65.536msec 6 (06h) 8μsec 13 (0Dh) 1.024msec 20 (14h) 131.072msec Isolated Digital Output Number of Output Channel 2500 V Optical Isolation Opto-isolator Response Time 50 µs 5 ~ 40 V Supply Voltage Sink Current 500 mA max/channel PCIE-1756H User Manual... -
Page 29: General
0 ~ +60° C (32 ~ 140° F) Operation (refer to IEC 68-2-1,2) Temperature Storage -20 ~ +70° C (-4 ~ 158° F) Relative Humidity 5 ~ 95% RH non-condensing (refer to IEC 60068-2-3) Certification CE Class A certified PCIE-1756H User Manual... - Page 30 PCIE-1756H User Manual...
-
Page 31: Appendix B Block Diagrams
Appendix Block Diagram... -
Page 32: Block Diagrams
Block Diagram PCIE-1756H User Manual... -
Page 33: Assignment
Appendix ADAM-3951 Pin Assignment... -
Page 34: Adam-3951 Pin Assignment
ADAM-3951 Pin Assignment Please refer to Figure C.1 and Figure C.2 for the pin assignments if you select Advantech ADAM-3951 as your wiring board for connecting to PCL-10250 and PCIE- 1756H. Figure C.1 Connect to PCL-10250 CON1 PCIE-1756H User Manual... -
Page 35: Figure C.2 Connect To Pcl-10250 Con2
Figure C.2 Connect to PCL-10250 CON2 PCIE-1756H User Manual... - Page 36 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
