Mountup MU0077-F Installation Instruction

INSTALLATION INSTRUCTION
If you have any questions, please feel free to contact our customer support
before returning.
Safety Caution
Please read this instruction carefully before installation. If you do not understand these
instructions or have doubts about the safety of the installation, assembly or use of this
product, please contact us.
● This product is designed for use in wood stud or solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount combined.
● Incorrect installation may result in product damage / property damage or body injury.
We shall bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are
missing or damaged, do not return the damaged item to your dealer; please contact our
customer service team. Never use damaged parts!
Must Check Before Getting Started
Verify Your TV Specifications:
VESA Pattern (W × H):
H
MIN: 75mm×75mm (3"×3")
MAX: 400mm×400mm (16"×16")
Verify Your Wall Construction:
< 5/8"(16mm)
Min.4"(102mm) CAUTION:
Avoid potential personal injuries and property damage!
Min.2"(51mm)
Drywall covering the wall must not exceed 5/8 in. (16 mm).
Max.16"(406mm)
Perfect!
Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm)
actual 1 ½ x 3 ½ in. (38 x 89 mm).
Wall with wood studs
Min. 4"
(102mm)
CAUTION:
Avoid potential personal injuries and property damage!
Perfect!
Mount the wall plate assembly directly onto the concrete
surface (no surface covering).
CAUTION: DO NOT install into drywall alone.
1
Product Dimensions
YZ2353_US1.0
144.5mm
(5.7)
200mm
(7.9")
Supplied Parts and Hardware
TV
Philips Philips
Screws Screws
M4×12mm M4×30mm M6×15mm
99 lbs
Load
(45 kg)
Capacity
WARNING: DO NOT exceed the
maximum weight indicated.
MA ×4 MB
Lag Bolt
ST6.3x60mm
A
NOTE: Not all parts and hardware included will be used.
Extra Tools You Need (Not Supplied)
For
Wood Studs
Stud Awl
Finder Drill Bit
435mm(17.1")
VESA
MAX:400mm(16")
MIN:75mm(3")
16"(406mm)
VESA
MAX:
122mm
(4.8") 400mm(16")
MIN:
399mm(15.7")
75mm(3")
Wall Plate TV Brackets
K J x1
x1
Philips Philips Philips Philips Washers
Screws Screws Screws Screws
Ф6mm
M6×30mm M8×25mm M8×45mm (M4~M6)
×4 MC ×4 MD ×4 ME ×4 MF ×4 MG ×4
Velcro Cable Ties
Bubble Level
T2
T1 ×1
x4
For
Concrete Wall
2M
Ф5/32" Ф3/8"
(Ф4mm) (Ф10mm)
Wood Masonry Hammer Band Pencil Electrodrill
Drill Bit Tape
2
1
Attach Brackets to TV
23mm(0.91")
1-1
Select TV Screws
Too Short Too Long
1-2
Need Spacer?
Yes, choose the appropriate screws, washers,and spacers for your TV.
Long Screw
Bracket
01
For more spacing
between bracket and TV
TV Brackets
I x1
No, just choose the screws, washers.
Bracket Short Screw
1-3
Spacers Spacers Attach Brackets to TV
H10mm H5mm
(M4~M8) (M4~M8)
MH ×8 MI ×8
J
×3
3/8"
(10mm)
MH MI MG
Socket Screwdriver May be needed Not for M8 Screws
Wrench
M8
M6
M4
Not Vertical Correct Correct
Washer
Spacer
TV back
02 03 04
For protruded For counterbore To avoid the
back TV of TV blocked input
Washer
TV back
TOP OF TV
Arrow Up
I
Push two brackets upward
to reduce the gap between
the holes and screws
Horizontal
Do not tighten the
screws excessively or
MA MB MC
tighten them by using
MD ME MF the Electrodrill, or your
TV might be damaged.
3
