- Page 1 Single Monitor Desk Stand Instruction Manual 75x75 MU0023 32" 100x100 8kg/17.6lbs If you have any questions , please contact us. V2.0...
-
Page 2: Package Contents
WARNING! If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, please contact us. Before starting assembly, verify all parts are included and undamaged. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Use the 4mm Allen Key (H) to tighten the screws (G) into the pole (D) from the bottom of the base (C). - Page 4 STEP 2 Slide the cable clip (E) onto the pole(D). Slide the mounting bracket (B) onto the pole(D). Tighten the mounting bracket (B) on the pole(D) using a 6mm Allen Key (I)
- Page 5 STEP 3 OPTION A: Flat Back Monitor For flat back monitor, secure VESA plate (A) to monitor using screws (M-A or M-C) and washers (M-E). CAUTION:To select the correct bolts(M-A or M-C) for your monitor, you can try to screw it on your monitor by hand.
- Page 6 STEP 4 Slide monitor with VESA plate onto mounting bracket. Secure with thumbscrew (F).
- Page 7 STEP 5 Tighten or loosen tilt joint using 6mm Allen Key (I). STEP 6 Manage cables with installed cable clip (E).
- Page 8 STEP 7 Store 4mm Allen Key (H) and 6mm Allen Key (I) in cable clip (E). STEP 8 Adjust monitor position and rotation. 90° +45° 360° -45° Note: When tilted, if the monitor sags or does not stay, please fasten the tilting bolt on the mount until the monitor can be held at any angle as needed.
-
Page 9: Product Dimensions
Product Dimensions 90° ±180°... - Page 10 CAUTION AND MAINTENANCE: • Never allow children to climb, stand, hang, or play on any part of monitor or stand. • This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury. •...
