Icom IC-M25 Instruction Manual page 19

■ Receiving and transmitting
CAUTION: DO NOT transmit without an antenna.
NOTE: Before using the transceiver for the first time, the battery pack must be fully
charged for optimum life and operation. See Section 4 for battery charging.
1. Push [▲] or [▼] to select a channel.
• When a signal is received, "
2. Hold down [PTT], and speak into the microphone to transmit.
• " " is displayed while transmitting.
3. Release [PTT] to receive.
TIP: To maximize the readability of your transmitted signal, pause for a second after
pushing [PTT] and hold the microphone 5 ~ 10 cm (2 ~ 4 inches) from your mouth, and
then speak at your normal voice level.
NOTE:
• To conserve battery power, the Power Save function automatically turns ON when no
signal is received for 5 seconds.
• When the temperature is extremely high, the battery protection function automatically
sets transceiver power to Low, and disables High power selection.
• The Time-out Timer function* cuts OFF transmission after 5 minutes of continuously
transmitting, to prevent prolonged transmission. 10 seconds before transmission is cut
off, a beep sounds to indicate the transmission will be cut off, and "tot" blinks. After it is
cut OFF, "tout" is displayed for 10 seconds, and you cannot transmit until it disappears.
* This function may not be installed, depending on the transceiver version.
2Push to transmit.
3Release to receive.
BASIC OPERATIONS
" is displayed.
1Select a channel.
5
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
10
