Icom IC-M25 Instruction Manual page 11

■ Supplied accessories
Belt clip
Antenna
Handstrap
■ Attaching accessories
D Antenna
Connect the supplied antenna to the antenna connector.
CAUTION:
• DO NOT carry the transceiver by holding only the
antenna.
• DO NOT connect an antenna other than those listed in
this instruction manual.
• DO NOT transmit without an antenna.
D Belt clip
To attach:
Slide the belt clip in the direction of the
arrow until the belt clip is locked and
makes a 'click' sound.
Belt clip
D Handstrap
Pass the handstrap through the loop on the back side of
the transceiver to make it easy to carry.
ACCESSORIES
USB cable
(Type-C/Type-A)
To detach:
Lift the tab up (1), and slide the belt clip in
the direction of the arrow (2).
BE CAREFUL! DO NOT break your
fingernail.
1
NOTE: Some accessories
may not be supplied, or the
shape may be different,
depending on the transceiver
version.
