01 - Table extension
02 – Suction hose
03 - Riving knive
04 - Suction hose Ø50
05 - Push rod
06 – Hose bracket
07 - Longitudinal aligning stop
08 - On/off switch
09 - Electrical connection
10 - Transverse cutting gauge
11 - Handwheel for height adjustment
12 - Handwheel for angle adjustment
13 - Saw blade Ø270
22 | GB
4
2
3
Accessories
Standard sliding carrier plate:
Standard sliding carrier plate
Stop rail:
Table extension
Base extension:
Table extension:
Complete transport device:
Comprising:
Wheel set with carry frame
Pallet truck
Saw blade guard
Precision adjustment
Table insert with collar nut
Stop ruler
6
12
11
Item no.
5301 0701
5301 0702
5320 8180
5463 0706
1901303701
79017 00701-0101
5300 0705
5300 0709
6247 0706
5460 1100
5410 7800
5300 0710
5300 0711
