ASROCK Rack 4U36L6E-ICX2/2T Quick Installation Manual

Quick Installation Guide
4U36L6E-ICX2/2T
System Overview
2
1
9
12 13
18
Front Panel & USB Cable Connections
NMI_BTN1
FPB Cable
L: 740mm
USB3_3_4
PANEL1
PANEL1
AUX_PANEL1
FPB Cable
L: 600mm
3
4
6
5
7
8
10 11
14 15
16
17
No. Item
1 Server Board (SP2C621D16-2T)
2 6 x PCIE Card Slots
3 12 x 3.5" Hot-Swap HDD Trays
4 2 x 2.5" Hot-Swap NVMe Trays
5 2 x Power Supply Units
6 Backplane Board (2-port BPB1)
7 Backplane Board (12-port BPB2)
8 Power Distribution Board (PDB)
9 Hot-Swap System Fan (FAN1)
10 Hot-Swap System Fan (FAN2)
11 Hot-Swap System Fan (FAN3)
12 Hot-Swap System Fan (FAN4)
13 Hot-Swap System Fan (FAN5)
14 Hot-Swap System Fan (FAN6)
15 Hot-Swap System Fan (FAN7)
16 Backplane Board (24-port BPB3)
20 x 3.5" SAS/SATA Drive Trays
17
4 x 3.5" SATA/SAS Drive Trays or 4 x 2.5" NVMe Drive Trays
18 Front Panel Board (FPB) (Front Controls and Indicators)
19
19 Front Panel Board (FPB) (2 x USB3.2 Gen1 Ports)
HDD Overview
Front Panel View
HDD20
HDD16
HDD12
HDD8
HDD4
HDD0 (NVME1)
HDD4~HDD23
HDD0~HDD3
Rear Panel View
USB Cable
L: 1000mm
HDD32
HDD28
HDD24
(for 2 x 2.5" NVME SSD)
(for 12 x 3.5" SAST/SAS HDD)
(for 24 hard disk drives, see item No. 17 for details.)
HDD21 HDD22
HDD17 HDD18
HDD14
HDD13
HDD10
HDD9
HDD5 HDD6
HDD2 (NVME3)
HDD1 (NVME2)
BLUE Supports 3.5" SATA/SAS drives
ORANGE Supports 3.5" SATA/SAS drives
or 2.5" NVMe (PCIe3.0 x4) drives
HDD33 HDD34
HDD30
HDD29
HDD26
HDD25
HDD23
HDD19
HDD15
HDD11
HDD7
HDD3 (NVME4)
HDD35
HDD31
HDD27
