- Page 1 INSTRUCTION...
-
Page 2: Exploded View And Parts List
EXPLODED-VIEW & PARTS LIST：... -
Page 4: Part List
PART LIST： Description Q’TY Description Q’TY Screw ST4.2*19*Φ8 Computer M5*10 Screw ST4.0*10*Φ6 Screw End cap Middle wire Belt 6PJ410 Handlebar Axle Φ25*16 End cap Belt pulleyΦ240 Φ23*3*630 Foam M6*15 Pulse Hex bolt ST4.0*19*Φ11 Screw Nylon nut L=800MM Bushing Φ17.2*Φ22*4 Handle pulse wire Φ12*11*Φ3 Bearing 6203-2Z Stopple... - Page 5 Steel bracket Screw Nylon nut M8*H7.5*S13 Tension spring Ф37*Ф32*24 Idle wheel Bearing 6000-RS Washer d6*Φ16*1.5 Hexagon bolt M6*12*S10 shipping tube Φ60 End cap Screw M8*72*20*S6 Allen wrench S13-14-15 Spanner 76L/R Pedal...
- Page 6 Assembly parts and tools:...
- Page 7 STEP 1: 1. nscrew bolt (73) with spanner and remove shipping tube (71). You may save these parts if you’d like to repackage and transport this elliptical in the future. 2. Attach front stabilizer (A) and rear stabilizer (B) onto main frame (28) with bolt(23) and washer (21).
- Page 8 STEP 2： 1.Attach the the seat(58) to the seat tube(55) with washer(21)and nylon nut(57), then tighten seat (58). 2.slide the seat tube(55) into the vertical seat post(51) and at the desired position,align holes and fix in place with the locking knob(53) and washer(54).Fix the seat cover(78) to the vertical seat post(51) with screw(2).
- Page 9 CAUTION: be sure the right pedal (76R) marked (R) is attached to the right crank arm and tightened in the clockwise direction.The left pedal (76L) marked (L) is attached to the left crank arm and tightened in the anticlockwise direction. STEP 3：...
- Page 10 a． Connect trunk wire(3) and sensor wire(17) well, Slide handlebar post (16) into Put the front plastic cover (27) to the support tube (16), the main frame (28).Then, tighten them with screw (20) STEP 4： Attach handlebar(4) onto handlebar post(16).
- Page 11 STEP 5： Prefasten the （13）to the handle（4） front cover Connect middle wire (3) and computer wire (1a). Attach computer (1)to support tube (16) with the screw (2).Then, plug handle pulse wire (9) into the hole which is at the back of computer. 3.
- Page 12 STEP 6： 1. Plug in the power adapter(77)to the main frame(28) when you want to use the machine. The assembly is complete!
- Page 13 INSTRUCTION MANUAL Key Functions START/STOP: 1. Start & Pauses workouts. . Start body fat measurement. 3.Operates only when in stop mode. Holding key for 3 seconds will reset all function value to be zero. DOWN : Decrease value of selected workout parameter: TIME, DISTANCE, etc. During the workout, it will decrease the resistance load.
- Page 14 “ 75 “of Weight will flash so Weight can be adjusted to use UP OR DOWN KEY , press ENTER KEY to save vale & move to next data. “30” of Age will flash so Age can be adjusted using UP OR DOWN KEY , press ENTER to save value. Press START/STOP to start measurement, please also grasp hand pulse grips.
- Page 15 GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.toorx.it - info@toorx.it...
