APEX CROSS TRAINER

OWNER'S MANUAL AND ASSEMBLY GUIDE

Table of Contents

Need help?

Do you have a question about the APEX XC1-XA-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness APEX XC1-XA-35

Page 1 APEX CROSS TRAINER OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
COMPLIANCES................9 PROPER USE.................10 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................14 PRODUCT FEATURES BASE OVERVIEW................25 CONSOLE OVERVIEW..............26 CARE AND MAINTENANCE INSPECTION................28 CLEANING THE EQUIPMENT............28 LEVELING THE MACHINE..............28 PREVENTATIVE MAINTENANCE............29 LONG TERM STORAGE..............29 ADDITIONAL INFORMATION TROUBLESHOOTING..............30 © 2025 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Do not move the equipment by lifting the console. Do not use the console as a • Close supervision is necessary when used near children under the age of 15, handlebar during a workout. or disabled persons. © 2025 TRUE Fitness All Rights Reserved.
Page 6 110V AC input and 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
XC1-XA-35 with the optional power supply. Up to 3 cross NEMA 6-15 Non-LED consoles require the trainers per 550 watts per 50/60Hz optional power supply. circuit—DO NOT cross trainer exceed © 2025 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
◦ 63” x 32” x 64” (160cm x 81cm x 163cm) • MAXIMUM USER WEIGHT ◦ Active Footprint 400 lbs / 181 kg 74” x 32” x 64” (188cm x 81cm x 163cm) © 2025 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
APPROVALS DATE DRAWN BY 12/5/2005 SCALE 1:1 DO NOT SCALE DRAWING SHEET 1 OF 1 This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.
Page 10: Proper Use
Place the opposite foot on the other side platform (if equipped). • Step down to the floor. NOTE: The elliptical trainer is not equipped with a free wheel, therefore the moving parts are unable to stop immediately. © 2025 TRUE Fitness All Rights Reserved.
Page 11: Assembly Instructions
IN BOX #2 Phillips Torque Wrench 13mm (Qty 2) and Screwdriver (optional but 17mm Wrench recommended) 6mm Allen Wrench Rubber Mallet Ratchet Wrench with 6mm Socket Bit and Extension Wire Cutters (optional but recommended) © 2025 TRUE Fitness All Rights Reserved.
Page 12: Box Contents
Left Front Shroud Right Front Shroud Left Handlebar Cover Right Handlebar Cover Mast Boot Left End Caps Right End Caps Battery Hardware Bag Manual Keep protective coverings on the shrouds until step 6. © 2025 TRUE Fitness All Rights Reserved.
Page 13: Hardware Pack Contents
NUT, HEX, NYLON INSERT, M10 X 1.5, CZ CLASS 10 105709-001 BOLT, M8 X 1.25 X 45 HCS, 12.9 STL, CZ 103393-001 NUT, HEX, NYLON INSERT, M8 X 1.25, CZ CLASS 10 100924-001 WRENCH, HEX, M6 107023-001 TIE, CABLE, W3.6 X L370 © 2025 TRUE Fitness All Rights Reserved.
Page 14: Assembly Steps
(17 ft-lb). when using a torque wrench = 23 N-M (17 FT-LB) B. Remove any protective coverings and verify the tracks and wheels are clean and free from debris. F. Reattach the track covers. © 2025 TRUE Fitness All Rights Reserved.
Page 15 D. Securely fasten the four console mast socket head cap screws. When using a torque wrench fasten to 23 n-m (17 ft-lb). base cables battery cables when using a torque wrench = 23 N-M (17 FT-LB) base cables © 2025 TRUE Fitness All Rights Reserved.
Page 17 D. Hook the plastic clip on the left moving handlebar cables over the hole in the E. Repeat steps A-D for the right moving handlebar. frame. Secure with an M4 screw. Connect the left moving arm cables to the cables in the base. © 2025 TRUE Fitness All Rights Reserved.
Page 18 Using a #2 Phillips screwdriver, fasten to the frame using two M5 screws from the hardware pack, and then fasten to the back shroud using the two previously removed M5 screws. © 2025 TRUE Fitness All Rights Reserved.
Page 19 (00567800). PVS power power button coaxial control do not heart rate connect power here ground power I/O data NOTE: Depending on the installation, PVS power may not be used. © 2025 TRUE Fitness All Rights Reserved.
Page 21 D. Position the shroud assembly on base frame. Insert and tighten four M5 screws to secure the shrouds in place. Remove all protective coverings from the shrouds. © 2025 TRUE Fitness All Rights Reserved.
Page 22 B. Wrap the mast boot around the base of the mast. A. Attach one left and one right frame end cover around each frame end and secure in place using six M5 screws (3 per side). © 2025 TRUE Fitness All Rights Reserved.
Page 23 IMPORTANT! Do not adjust the leveling feet to such a height that they detach or unscrew from the machine. B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock lock leveling leveling foot foot © 2025 TRUE Fitness All Rights Reserved.
Page 24 Please follow the instructions included with your console for important configuration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 25: Product Features Base Overview
Patented, one-of-the-kind converging path and multigrip handlebars to better engage the upper body and fit every exerciser comfortably. Check heartrate without wearing a wireless chest strap. H. Stationary Handlebars Helps to stabilize the upper body during lower body only exercises. © 2025 TRUE Fitness All Rights Reserved.
Page 26: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
Page 28: Care And Maintenance
CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any parts of the machine. Allow the machine to dry completely before using. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation.
Page 29: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 30: Additional Information Troubleshooting
Obtain set top box from video provider Verify video type with provider; analog (NTCS), digital air (ATCS), digital cable (QAM) Channels or format type not correct Rescan TV channels Tuner Invalid Contact TRUE Product Support © 2025 TRUE Fitness All Rights Reserved.
Page 31 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
Page 32: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or 1 Year Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
Page 33: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
Page 34: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
Page 35: Warranty Registration
St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
Page 36 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC1-XA-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
