Summary of Contents for True Fitness XFW5510

  • Page 1 XFW5510 LEVER ROW SCAN FOR UP-TO-DATE OWNER’S MANUAL OWNER’S MODEL XFW5510 MANUAL (MAN-XFW5510 REV00)
  • Page 3: Important-Please Read

    IMPORTANT—PLEASE READ All products shown are prototype. Actual product delivered may vary. Product specifi cations, features, and software are subject to change without notice. For the most up-to-date version of this manual, please see our website: https://truefi tness.com/services-support/user- manuals/ CONTACTING OUR SUPPORT TEAM To contact TRUE for any of your pre or post installation questions, please call our toll-free numbers Monday - Friday 8:30am - 5:00pm (CST): •...
  • Page 4: Reporting Freight Claims Or Parts Damage

    REPORTING FREIGHT CLAIMS OR PARTS DAMAGE Unfortunately, sometimes materials can be damaged during shipment. If materials are damaged during shipment, please follow the guidelines below to determine the appropriate process for you to follow. Severe Damage—Obvious damage to external packaging and internal product. Please refuse the shipment and it will be returned to TRUE by the carrier.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS..................6 GENERAL CARE AND MAINTENANCE............................8 COMMERCIAL MAINTENANCE SCHEDULE..........................9 COMPLIANCES..................................9 DIMENSIONS AND WEIGHTS..............................10 LABEL LOCATIONS.................................11 WARNING AND INTENDED USE LABELS..........................11 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST..............................13 ASSEMBLY STEPS..................................16 PREVENTATIVE MAINTENANCE DAILY INSPECTION AND MAINTENANCE..........................22 WEEKLY INSPECTION AND MAINTENANCE..........................22 OTHER SCHEDULED PREVENTATIVE MAINTENANCE......................22 CLEANING THE EQUIPMENT..............................23...
  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS FACILITY AND USER SAFETY PRECAUTIONS • Review and understand all of the warning labels affi xed to this machine and on the facility safety sign. • Be certain that the machine operation is understood before it is used. Refer to the instructional procedure label affi xed to the machine.
  • Page 7: Installation Safety Precautions

    INSTALLATION SAFETY PRECAUTIONS • Read this installation manual entirely before assembling this equipment. • Verify that there is adequate space surrounding this piece of equipment for safe access and operation. Installation must meet ADA requirements for accessibility. • Install this piece of equipment on a solid level surface that does not deviate more than 1/8” over a 10’ distance (or as defi...
  • Page 8: General Care And Maintenance

    GENERAL CARE AND MAINTENANCE IMPORTANT Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the SAFETY section of this document and the items that follow here, should be included in your maintenance program.
  • Page 9: Commercial Maintenance Schedule

    COMMERCIAL MAINTENANCE SCHEDULE Commercial Maintenance Schedule Daily Weekly Monthly 6 Months Annually Inspect all nuts and bolts and tighten if needed. Inspect safety catches, stop rods, and their fasteners. Replace at the fi rst sign of wear. Inspect all anti-slip surfaces and replace as needed. Inspect all accessory bars and handles.
  • Page 10: Dimensions And Weights

    DIMENSIONS AND WEIGHTS • ASSEMBLED DIMENSIONS (W X L X H) 44" x 73” x 47” / 111 cm x 185 cm x 119 cm HEIGHT 47” 119 cm WIDTH LENGTH 44” 73” 111 cm 185 cm ∙ PRODUCT WEIGHT 180 lbs / 82 kg ∙...
  • Page 11: Label Locations

    LABEL, TRUE LOGO WHITE 10 IN LBL-PR-XFW55 LABEL, INTENDED USE LBL-WRN-0010 LABEL, XFW GENERAL WARNING SL-XFW5510-35 LABEL, SERIAL NUMBER WARNING AND INTENDED USE LABELS WARNING: Replace all labels that may be worn, damaged, or missing. To replace any worn or missing decals contact TRUE product support (service@truefi tness.com | 800.883.8783).
  • Page 12 Part# and Description Image LBL-WRN-0010 (General Warning) SL-XFW5510-35 (Serial Number) TRUE FITNESS TECHNOLOGY, INC 865 HOFF RD, ST LOUIS MISSOURI 63366 USA MODEL NO: XFW5510-35 SERIAL NO: 25-XFW551000A LBL-LOG-010BK (Logo)
  • Page 13: Assembly Instructions

    ASSEMBLY INSTRUCTIONS NOTE: Supplemental video available on YouTube: https://www.youtube.com/@TRUEFitnessservicevids PREASSEMBLY CHECKLIST CAUTION: Use caution when assembling this product. Unpacking and assembling this product requires two or more people. Use caution when unpacking this product. Avoid damage to the product and product pads. DO NOT use a box cutter.
  • Page 14: Box Contents

    BOX CONTENTS BOX CONTENTS Item Image Item Image Base Frame Pad Protector Grip Handle Left Side Frame Pivot Axle Right Side Frame Hardware pack Manual Pad Frame Lever Arm Foot Plate...
  • Page 15 HARDWARE PACK CONTENTS XFW5510 HARDWARE PACK XFW5510 HARDWARE PACK ITEM DESCRIPTION ITEM DESCRIPTION HHS, 3/8"-16, 1-1/4", LOCKING BHCS, 1/2"-13 X 1-1/4", LOCK PATCH PATCH C 696LP C 446LP LOCK WASHER LOCK WASHER, 3/8", ZP 13.5ID*21.3OD*2.5THK C 749 C 750 WASHER, FLAT, 3/8" USS WASHER, FLAT, 1/2"...
  • Page 16: Assembly Steps

    ASSEMBLY STEPS STEP 1—ATTACH PAD FRAME ASSEMBLY TO THE BASE FRAME ASSEMBLY Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW55-BF000X-35 BASE FRAME ASSEMBLY, MATTE BLACK XFW55-MF000X-35 PAD FRAME ASSEMBLY, MATTE BLACK C 446LP HHS, 3/8"-16, 1-1/4", LOCKING PATCH C 749...
  • Page 17 STEP 2—ATTACH SIDE FRAME ASSEMBLIES TO THE BASE FRAME AND PAD FRAME ASSEMBLIES Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench XFW55-FF000X-35 LEFT SIDE FRAME ASSEMBLY, MATTE BLACK XFW55-FF010X-35 RIGHT SIDE FRAME ASSEMBLY, MATTE BLACK C 446LP HHS, 3/8"-16, 1-1/4", LOCKING PATCH C 749...
  • Page 18 STEP 3—ATTACH LEVER ARM ASSEMBLY TO THE PAD FRAME ASSEMBLY Tools Used in this Step Parts Used in this Step 5/16" Allen Wrench ITEM PART# DESCRIPTION XFW55-AX001 AXLE, PIVOT XFW55-AR150X-35 LEVER ARM ASSEMBLY, MATTE BLACK C 696LP BHCS, 1/2"-13 X 1-1/4", LOCK PATCH C 750 LOCK WASHER 13.5ID*21.3OD*2.5THK Rubber Mallet...
  • Page 19 STEP 4—ATTACH GRIP HANDLE ASSEMBLIES TO THE LEVER ARM ASSEMBLY Parts Used in this Step ITEM PART# DESCRIPTION XFW55-GR001X-35 ASSEMBLY, GRIP HANDLE, MATTE BLACK D 865 ROLL PIN, 1/4" X 1-1/4", SLOTTED Attach the grip handle assemblies to the lever arm assemblies using 2 slotted roll pins.
  • Page 20 STEP 5—ATTACH FOOT PLATES TO THE BASE FRAME ASSEMBLY Tools Used in this Step Parts Used in this Step 6mm Allen Wrench ITEM PART# DESCRIPTION IT80261500V1 FOOT PLATE, RUBBER MOLDED IMP_PNLM815 BHCS, M8 X 15MM LG C 758 LOCK WASHER, 5/16" SPLIT, ZINC C 753C WASHER, FLAT, 5/16 SAE ZINC Using a 6mm allen wrench, attach the foot plates to the base frame assembly using 8 hex screws, 8 lock washers, and 8 fl...
  • Page 21 STEP 6—ATTACH PAD AND PAD PROTECTOR TO THE PAD FRAME ASSEMBLY Tools Used in this Step Parts Used in this Step 9/16" Socket ITEM PART# DESCRIPTION Wrench PAD-CH001-00X PAD, 205 X 400, TAPERED, BLACK WITH SINGLE BLACK STITCH XFW55-CH001 PLASTIC, PAD PROTECTOR C 446LP HHS, 3/8"-16, 1-1/4", LOCKING PATCH C 749...
  • Page 22: Preventative Maintenance

    PREVENTATIVE MAINTENANCE Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these products. As a minimum, the items presented in the Safety Instructions section of this document and the items that follow here, should be included in your maintenance program.
  • Page 23: Cleaning The Equipment

    CLEANING THE EQUIPMENT Daily Cleaning Wipe all machines with a water dampened cloth and dry completely. This includes painted parts, chrome plated parts, plastic parts, and upholstered pads. It is important not to leave parts damp. This will increase the potential for corrosion to occur. CAUTION: Certain anti-bacterial cleaners and other harsh cleaning agents can induce corrosion on the machine components.
  • Page 24: Warranty Information

    fi lled in, signed by the original purchaser, and mailed to TRUE. **Labor warranty is available for equipment located within United States. TRUE Fitness equipment is automatically covered under a 6-month Limited Labor Warranty. This 6-month Limited Labor Warranty begins from the date of purchase shown by a valid receipt.
  • Page 25: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original product purchaser and the parts of the TRUE product (the “Product”) listed below. During the applicable Warranty Period, the Product, under normal use and service, shall be free of manufacturing defects in workmanship and materials.
  • Page 26: Warranty Registration

    QR Code: Scan the QR code below with your smartphone to be base serial taken directly to the registration page. number location TRUE FITNESS TECHNOLOGY, INC 865 HOFF RD, ST LOUIS MISSOURI 63366 USA OURI 63366 OURI 63366 • By Mail:...
  • Page 28 1.800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XFW5510 Owner’s Manual, Assembly Guide, and Warranty Card REV00 © 2025 TRUE Fitness All Rights Reserved...
