Summary of Contents for ITC TS-0200M
- Page 1 Fully Digital Congress System User Manual TS-0200M/MC/ME TS-0221 TS-0206/0206A TS-0203/0203A/0204/0204A TS-0670HY Before using this system, please read this manual carefully...
- Page 2 User Manual Fully Digital Congress System Fully Digital Conference System TS-0200 series fully digital conference system - 2 -...
-
Page 3: Table Of Contents
2.4 TS-0203/TS-0203A Chairman unit / delegate unit..............15 2.5 TS-0206/TS-0206A Chairman/Delegate Unit................18 2.6 TS-0670HY Fully digital conference interpreter machine unit..........20 2.7 TS-0200ME Extension Unit......................22 3. Conference controller Operation Manual TS-0200M............... 23 3.1 Boot..............................23 3.2 Conference Mode..........................23 3.2.1 FIFO Mode..........................23 3.2.2 Normal mode.......................... - Page 4 User Manual Fully Digital Congress System 4.2 Unit type............................33 4.3 Meeting management........................33 4.4 Sign in............................. 34 4.5 Voting.............................. 34 4.6 Channel selection..........................35 4.7 Fire alerting............................ 35 4.8 Other functions..........................35 4.8.1 Language settings......................... 35 4.8.2 Timing speech and speech timing..................35 4.8.3 Audio adjustment........................
- Page 5 User Manual Fully Digital Congress System 7.15 Volume adjustment function......................48 7.16 Other functions..........................48 8. TS-0670HY operation explanation....................49 8.1 Proceed ID installation......................... 49 8.2 Model Management........................49 8.3 Fire Alarmt............................51 8.4 Main interface channel switch.....................51 8.5 Tea Application..........................51 8.6 Ask for Help............................
-
Page 6: System Introduction
Fully Digital Congress System 1. System introduction 1.1 Brief introduction TS-0200 Series fully digital conference system adopts ITC innovative network communications and digital transmission processing technology which has completely independent intellectual property rights. This leads the meeting field to a new breakthrough. - Page 7 User Manual Fully Digital Congress System Note: Aircraft Power Details table model TS-0206/0206A TS-0203/0203A TS-0670HY TS-0204/0204A TS-0221 Power(W) - 7 -...
-
Page 8: Product Description
User Manual Fully Digital Congress System 2. Product Description 2.1 TS-0200M Digital Conference System Controller Function 1. Digital audio transmission technology, simultaneous interpreting channel number 63+1, speech separation technology. 2. Super extensions function, system microphone capacity of 4096, hand in hand connection, support hot swapping. - Page 9 User Manual Fully Digital Congress System The front panel, back panel features 1. LCD screen, used to display the current working state. 2. Conference speech unit communication indicator. 3. The power switch and the power input socket, support AC ~110V-240V input. 4.
-
Page 10: Specifications
User Manual Fully Digital Congress System Specifications Model TS-0200M Microphone Capacity ≤4096 Channel Quantity 16, 32, 64CH Frequency Response 30~20KHz S.N Ratio >75 dB(A) Dynamic Range >80 dB Channel Isolation >80 dB Total Harmonic Distortion <0.05% Power Supply 90~132V AC/180~264V AC by switch... -
Page 11: Ts-0221 Fully Digital Conference System Of Multi Function Expansion Box
7. Three exchange controller port, SSRAM, 10/100M Ethernet port, each interface supports IEEE802.3, IEEE802.3u, IEEE802.3x standard, has strong anti interference ability. Function Introduction 1. LINK— Connect TS-0200M conference system controller or connect an extension box NEXT interface. 2. Power input interface, DC 36V input. -
Page 12: Ts-0206/Ts-0206A Chairman/Delegate Unit
User Manual Fully Digital Congress System Specifications Model TS-0221 Maximum power consumption 1.5W Supply Voltage Connection Dedicated cable (6-pin) Color Silver Weight About 0.5Kg Size(L*W*H) 156 x 111 x 32mm Working Temperature -10℃~+60℃ Working Humidity 20% to 80% relative humidity, non-condensing 2.3 TS-0206/TS-0206A Chairman/Delegate Unit Of Digital Interpretation Conference System Features... - Page 13 User Manual Fully Digital Congress System Function Introduction Chairman Unit (TS-0206) Delegate Unit(TS-0206A) ① Loudspeaker. ② Microphone Interface. Microphone 6 core air interface foot position function description: ③ LCD screen. ④ Channel selection key, used to select the current interpreter machine channels. ⑤...
- Page 14 User Manual Fully Digital Congress System Notice: Long press the chairman unit number "1" 3 seconds to vote; The state of the vote, a vote for the last time effectively, to speak unit has the memory function can write down the last key, vote by indicating lamp display;...
-
Page 15: Ts-0203/Ts-0203A Chairman Unit / Delegate Unit
User Manual Fully Digital Congress System Voting Five-button voting, Three -button voting Simultaneous Interpretation 16, 32, 64 channel (default 16) Check-in Function Button sign Display Screen English character full dot-matrix LCD display Weight 0.9kg Microphone pole height 415mm Dimension(L*W*H) 225*131*48mm Installation Desktop 2.4 TS-0203/TS-0203A Digital conference electronic table card Chairman unit /... -
Page 16: Products Introduction
User Manual Fully Digital Congress System 12. With the function of electronic table stands, with full view large LCD to shows the person’s name, can be quickly update the display information through PC. 13. Can choose receive (15+1)/(31+1)/(63+1) channel language. 14. - Page 17 User Manual Fully Digital Congress System Specifications Model TS-0203/TS-0203A Microphone Types Heart-shaped directivity electret Microphone Frequency Response 80Hz~16KHz Input Impedance 1KΩ Sensitivity -46 dBV/Pa Maximum SPL 100dB(THD>3%) >80dB(A) Crosstalk >70dB Dynamic Range >80dB <0.1% Maximum Power Consumption 5.5W Headset Load >16Ω...
-
Page 18: Ts-0206/Ts-0206A Chairman/Delegate Unit
User Manual Fully Digital Congress System 2.5 TS-0204/TS-0204A Fully digital conference with IC card sign Chairman Unit / Delegate Unit Features 1. Microphone adopt 48KHz sampling rate, higher than CD sound quality,the voice is clear and bright. Internal DSP audio processing, there is no low frequency sound. 2. - Page 19 User Manual Fully Digital Congress System Products introduction ① Registration card slot port. ② headset microphone port. ③ headphone output. ④ 4.3 inch touch screen. ⑤ Microphone on behalf of unit key. ⑥ chairman unit microphone on the key. ⑦ chairman unit microphone priority button. Specifications Model TS-0204/TS-0204A...
-
Page 20: Ts-0670Hy Fully Digital Conference Interpreter Machine Unit
User Manual Fully Digital Congress System Power supply Host power supply DC36V Color Black Voting Five-button voting, Three -button voting Simultaneous Interpretation 16,32,64 channel (default 16) Check-in Function Button sign，IC card sign IC Card With Contact IC card Display 4.3-inch Color Screen Weight 1.17kg Microphone pole height... -
Page 21: Functions Introduction
User Manual Fully Digital Congress System 10. Can preset 3 fast input channels with a corresponding shortcut keys (a/b/c). 11. Selection button of input channel, and can choose easily in all the input language channel. 12. Can preset 3 fast output channels with a corresponding shortcut keys (A/B/C). 13. -
Page 22: Ts-0200Me Extension Unit
User Manual Fully Digital Congress System Display 7-inch color touch screen Weight 1.65kg Microphone Pole Height 415mm Size（L*W*H） 268x160x63mm Installation Desktop 2.7 TS-0200ME Extension Unit Features 1. Dedicated 6-core cable connection. 2. With full digital conferencing system to expand speech units. 3. -
Page 23: Conference Controller Operation Manual Ts-0200M
① If TS-0200ME device is present, the priority extend all meetings start hosts. ② Open TS-0200M conference host Power On/Off. ③ Is there an error on the boot prompt to view the conference host panel screen, if so, then there is a problem device, check to solve. -
Page 24: Normal Mode
User Manual Fully Digital Congress System Open mic full Hint: Chairman machine between each other without FIFO mechanism, the total number N and has reached full open microphone President machine, and then open a new chairman unit, its interface will show "microphone full". Priority: key priority by the President of the machine, start the Chairman priority function, which immediately shut off all delegate microphones open state. -
Page 25: Apply Mode(Apply)
User Manual Fully Digital Congress System Priority: key priority by the President of the machine, the machine starts Chairman priority function, which immediately shut off all delegate microphones open, wait state. If this does not open microphones until President, the Chairman of the machine will turn on the microphone (in the current number of full and open mic the whole machine is President, the President microphones do not open). -
Page 26: Volume Control
User Manual Fully Digital Congress System ① Software edit ID, enter the series ID interface in the function main interface. If you need to change the start ID number, you can select the starting ID number box, press the keyboard settings (ranging from 1 to 4096), the value press "OK"... -
Page 27: System Configuration
User Manual Fully Digital Congress System From entering the function interface to system condition interface, you can check the current on-line units’ qty and types. The current system has the chairman unit, delegate unit, interpreter unit. You can check the system actual changing condition by inserting the current chairman unit, delegate unit (the detection time for the controller insertion is 1 min under the whole controller spare condition, if not present the actual updating, please patiently wait for its changed value to check whether, but it is prohibited to insert the delegate frequently). -
Page 28: Restore Default Data Configuration
User Manual Fully Digital Congress System 3.6.3 Restore default data equipment Enter the restore default interface, make sure if really needs to implement the restore default. Restore default means restore Factory Settings value, the default data is as followings: Conference mode: FIFO, Max Mic qty: 1 Conference Max signed person: 999 Program ID: original ID: 0001 Default touch screen display: Simplified Chinese, Max brightness: 64... - Page 29 User Manual Fully Digital Congress System ③ Please check CobraNet module IP add (module PCB has mark), the followings explain the already known CobraNet module IP adds: 192.168.0.1/192.168.0.42. ④ When PC IP is 192.168.0.1~192.168.0.255, you can check CobraNet module online. ⑤...
- Page 30 User Manual Fully Digital Congress System ⑨ Installation sending end. The operation is the same as the receiving end and after finishing, you can see the below picture. After installing, please click OK, and return to the third step to check the green icon, then the installation is successful.
-
Page 31: Camera Controlling
User Manual Fully Digital Congress System 3.8 Camera control Conference controller support VISCA/PELCD_D camera protocol, the user can be directly connected by 232/422 single camera, also can connect camera tracking and connect more cameras, camera Settings you need to use PC software implementation. 3.8.1 camera connection and configuration ①... -
Page 32: Fire Alerting
CH0 is the source channel, CH1~CH21 is 21, the interpreter machine translated speech output channel. 3.10.3 optical fiber communication The controller has FIBER interface is optical FIBER communication, can use two TS-0200M host with optical FIBER line connection, currently available to transmit music in the background. 3.10.4 extension controller Host behind the EXTENSION expansion socket connection, the current can be an external TS-0221, cascade TS-0206 can be normal use of the function. -
Page 33: The Instructions Of Meeting Unit Ts-0206/Ts-0206A
User Manual Fully Digital Congress System 4. The instructions of meeting unit TS-0206/TS-0206A 4.1 open Open the controller power supply start up conference system, the screen "in the digital conference system start...", after the completion of the boot screen LOGO interface unit "on behalf of" or "chairman unit"... -
Page 34: Sign In
User Manual Fully Digital Congress System When press the number key “ 3” on chairman unit, the applying delegate units will open by first in first out mode. When under NORMAL mode, the exceeded delegated will enter into waiting status. If waiting person is full, it will remind waiting person is full. -
Page 35: Channel Selection
User Manual Fully Digital Congress System Long press number key 5 again to quit vote function and back to LOGO interface. PC launches 5-key voting as below, press one number to vote. PC launches 5-key assessment as below, press one number to make assessment. 4.6 Channel Selection By switching CH + / CH- button, user can select the channel to listen to the translated language. -
Page 36: Audio Adjustment
Port NEXT/ UNIT1 / UNIT2 state of light is the same. When no external 36V power supply, a TS-0200M host most can connect to 48 units of TS-0221, after the external DC 36V power supply, quantity can support the maximum number of units. -
Page 37: Ts-0203/0203A Operation Manual
User Manual Fully Digital Congress System 6. TS-0203/0203A Operation Manual 6.1 Boot Power on the host system to start the meeting, unit machine screen display "System Loading ...", the start up page as follows. After completion of the boot LOGO interface touch screen display, if the machine is not normal, you can not automatically switch to LOGO interface. -
Page 38: Sign In
User Manual Fully Digital Congress System In APPLY mode, when the applications on behalf of open mics, representatives shown below: Chairman of the machine at this time are shown below. Then press the button to agree or disagree, on behalf of the application is turned on or off according to the FIFO mode. -
Page 39: Vote
User Manual Fully Digital Congress System Chairman unit sign control interface Chairman unit menu Interface At this point you can view on the touch screen display and has not yet reached the number of attendance numbers, you can also initiate attendance by PC software. At this point you can select by pressing the microphone key unit machine, press the "sign"... -
Page 40: Channel Selection
User Manual Fully Digital Congress System PC software can be launched five key rating, press the corresponding button, select a result, as shown in the figure below: 6.6 Channel selection Chairman unit and delegate unit on the page icon LOGO channel switching current audio listening, you can choose to listen to different sound channels manually (with power-down save function), where 0 is the original sound output channel, and the remaining 15 for... -
Page 41: Timing Speech And Speech Timekeeping
User Manual Fully Digital Congress System 6.9 Timing speech and speech timekeeping This function need to switch controlled by the PC software, please refer to the PC user manual. Its function is to switch the phone, in the timing speech, PC issued regularly speak of time, the unit will display the countdown time remaining presentation, the time to automatically shut down after phone, timing speech only for the delegate unit effectively, the chairman of the unit is invalid;... -
Page 42: Tea Application Functionality
User Manual Fully Digital Congress System 6.13 Tea Application Functionality Enter the menu page, as shown below, Click on tea button is to apply for tea from PC software, the PC software tea application will light up to alert, chairman unit and delegate unit menu page as shown in the figure below: Chairman unit Delegate unit... -
Page 43: Ts-0204/0204A Operation Manual
User Manual Fully Digital Congress System 7. TS-0204/TS-0204A Operation Manual 7.1 Booting Power on the host system to start the meeting, unit machine screen display "System Loading ...", the start up page as follows. After completion of the boot LOGO interface touch screen display, if the machine is not normal, you can not automatically switch to LOGO interface. -
Page 44: Sign In
User Manual Fully Digital Congress System In APPLY mode, when the applications on behalf of open mics, representatives shown below: Chairman of the machine at this time are shown below. Then press the button to agree or disagree, on behalf of the application is turned on or off according to the FIFO mode. -
Page 45: Vote
User Manual Fully Digital Congress System Chairman unit sign control interface Chairman unit menu Interface At this point you can view on the touch screen display and has not yet reached the number of attendance numbers, you can also initiate attendance by PC software. At this point you can select by pressing the microphone key unit machine, press the "sign"... -
Page 46: Channel Selection
User Manual Fully Digital Congress System PC software can be launched five key election, press the corresponding button, select a result, as shown in the figure below: PC software can be launched five key rating, press the corresponding button, select a result, as shown in the figure below: 7.6 Channel selection Chairman unit and delegate unit on the page icon LOGO... -
Page 47: Chinese-English Switch
User Manual Fully Digital Congress System 7.8 Chinese-English Switch From the LOGO page click the menu button to enter the menu page, click language Settings button to enter Chinese-English switch pages, power-down save. Settings page is as follows: 7.9 Timing speech and speech timekeeping This function need to switch controlled by the PC software, please refer to the PC user manual. -
Page 48: Electronic Nameplate Function
User Manual Fully Digital Congress System 7.13 Screen brightness adjustment Chairman unit enter the menu page, click on "Brightness Adjustment" button to adjust the screen brightness chairman unit, the screen brightness adjustment range of chairman unit is: 0 to 64; brightness adjustment delegate directly unit icons in the lower right corner of the page LOGO chairman unit brightness adjustment delegate 7.14 volume adjustment function... -
Page 49: Ts-0670Hy Operation Explanation
User Manual Fully Digital Congress System 8. TS-0670HY operation explanation 8.1 Proceed ID installation Sponsor edit ID through controller touchable screen, interpreter enter edit ID interface, then it will show the current room number, current ID number, local room number and local ID number. As shown below: Write ID interface click OK button, the mic red color will flicker one time, when it stop at red color, which means ID is... - Page 50 User Manual Fully Digital Congress System Interpretation room interlock mode: When you select "Interlock" mode, if there is a microphone in the interpretation room opened, other interpretation unit can not be opened, if you want to open the unit has the same output channel of opened delegation.
-
Page 51: Fire Alarmt
User Manual Fully Digital Congress System 8.3 Fire Alarm The host is fire alarm, interpretation units will come into fire alarm interface, it will work until fire alarm revocation. 8.4 Main interface channel switch The main interface show below when opening: start interface main interface As mentioned in main interface:... -
Page 52: Ask For Help
User Manual Fully Digital Congress System Tea interface 8.6 Ask for Help Click the Help application icon (Help) after helping to launch PC applications jump to help translators machine interface interface that helps the application is successful, the PC will be prompted, click Return Homepage button to return to the main interface. -
Page 53: Volume Adjustment
User Manual Fully Digital Congress System 8.9 Volume adjustment Click the volume icon (volume), enter the volume control interface, click the + and - buttons to adjust the volume of headphones and speakers, you can drag the progress bar in the middle of the volume adjustment. -
Page 54: Fast Output Channel Presets
User Manual Fully Digital Congress System 8.12 Fast output channel presets Click Setup to enter the setup interface, then click Pre-set fast output channel into the fast output channel preset interface, click A, B, C can be selected switch, was selected for the yellow, + - buttons perform the corresponding language channel adjustment (1-15), After choosing the click OK to save the default input language fast, click the Return button return to the Setup interface. -
Page 55: Message
User Manual Fully Digital Congress System Brightness control interface 8.15 message When there is message, a red dot will appear on the top right corner of the envelope, click on the envelope will enter message interface to view, read it and then click on the Homepage to return to the main interface, after reading the envelope of the red dot will disappear. -
Page 56: Ts-0200Me Extension Unit
/0200MC/0200ME each other cascade port. DELEGATES 1/2/3 port is used to connect the conference units machine, and TS-0200M's DELEGATES port function, the use of the method is the same. When a user connects to the corresponding port, the port is working properly, the front panel of the TS-0200ME corresponding indicator light, if the data is sent over the link, the indicator light flashes. -
Page 57: Conference Pc Software Instruction
System management includes the sub-modules: user management, host configuration. Due to the limited space in this manual, the specific operation of the digital conference system software instructions here is not mentioned in details, please refer to "ITC Digital Conference System Software User Manual”. -
Page 58: Core Aviation Connector Description
User Manual Fully Digital Congress System 11. 6-core aviation connector Description 6-core aviation connector pin illustrated Air 6P interface pin definitions Air 6P extension cord pin illustrated: Air 6P extension cable pin assignment 12. Outputting and loading capacity sheet of the controller machine/extension (single) of Conference system Extension cable length between the host machine and the first conference unit (The... - Page 59 User Manual Fully Digital Congress System Speaker and TS-0670HY microphone with 7 inch color touch screen Speaker and Quantity of microphone with 4.3 TS-0204/0204A inch color screen (containing quantity of TS-0221) Speaker and TS-0236/0236A microphone with 0 LED (without TS-0221) screen Speaker and TS-0205/0205A...
- Page 60 User Manual Fully Digital Congress System Full Digital Congress System - 60 - VersionV0.5...
