- Page 1 Intelligent digital conference system User Manual TS-0627/TS-0627A...
- Page 2 Notice: This user manual is only for operating indication not for repairing indication. If there is any modification on the functions or specifications of the units, additional instruction will be issued accordingly. Please consult with the manufacturer for more information about it. The copyright of this user manual belongs to the manufacturer.
- Page 4 1. Intelligent Digital Conference System About ITC intelligent digital conference system Intelligent digital conference system is a high-tech series including discussion speech, simultaneous interpretation, infrared voice distribution, teleconference, voting, and camera tracking and so on. Adhering to the idea of highly integration, it meets the close compatibility of DCS (Digital conference system) and MCS (Multimedia central control system), forming a comprehensive intelligent conference system.
-
Page 5: Functions And Features
2. DCS control system Functions and features 1. unique patented technology, special anti-RF radio frequency interference hose, completely eliminate from noise, presenting a perfect senior conference environment. 2. Unique patented technology fully embodies the world aesthetic trend. 3. Unique microphone cover, without using windproof cotton cover, the "bubbling" low impact sound can be completely eliminated. - Page 6 TS-0627/0627A Function introduction 1. ON/OFF -- MIC switch key 2. PRIOR -- the microphone priority keys. Chairman unit (TS-0627) has special priority, press this button to cancel all speaking unit speech authority at any time, and to open the chairman MIC 3.
- Page 7 Turn on the conference host, and turn the SETID switch on the host to ON position. Then begin setting the ID. Pressing ON/OFF button on TS-0627/0627A, the mic lamp will flash and then keep in red, which means the success of ID setting. After that, press ON/OFF button and turn the SETID switch to OFF to turn off all the mic lamps.
- Page 8 After inputting background music by the conference controller, you could hear music from the speaker built-in TS-0627/0627A when the mic is not used. But once the mic is used, the speaker will stop playing music. If connect the headphone or record interface, the speaker will be mute and the audio will be output from the headphone.
- Page 9 7) Chinese-English Shift Long press ON/OFF key till there is display of Chinese-English Shift. 8) IC plug-in card function test In the sign-in mode, if insert the IC card, it means registration; otherwise, the screen will only display the LOGO. Picture 1 Picture 2 Picture 3...
-
Page 10: Technical Datas
Technical datas: Power Supply DC24V (powered by the controller) Connector 8 pins particular connector Power consumption Earphone output 9dBu，8-32Ω，3.5mm mini socket ≤2W Speaker power Microphone type High directivity electret microphone Directivity Cardioid type > 80dB Crosstalk > 80dB Distortion < 0.10% Frequency Response 60－16kHz ≈20dB SPL...
