Summary of Contents for ITC TS-0205
- Page 1 Fully Digital Conference System User Manual TS-0205 TS-0205A Before using this system, please read this manual carefully...
- Page 2 Fully Digital Conference System User Manual Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
- Page 3 Fully Digital Conference System User Manual ● This product uses a power plug or appliance input socket as a disconnecting device with the power supply, and must be disconnected if necessary for safety reasons. ● This equipment is only suitable for safe use at altitudes under 2000 meters. Precautions 1.
- Page 4 Fully Digital Conference System User Manual 5. Agreement Please strictly follow the instructions in this manual. The software, hardware and appearance of this product will be upgraded and updated continually. The above changes will be made without notice. Non-professional maintenance personnel, do not remove the product, to avoid damage and electric shock.
-
Page 5: Table Of Contents
2.1 Fully Digital Conference Built in Interpretation Chairman/Delegate Unit(With 4.3 Inch Capacitance Color Screen )......................7 2.2 Features............................. 7 2.3 Product Function Introduction....................8 2.4 Technology Parameter.......................8 3. Conference Unit TS-0205/0205A Operating Instructions.............9 3.1 Start up............................9 3.2 Unit Type..........................10 3.3 Meeting Management ......................10 3.4 Sign In............................. 11 3.5 Voting............................ -
Page 6: System Introduction
1. System Introduction 1.1 Sketch TS-0200 series full digital conference system using ITC company unique with complete proprietary intellectual property rights internet communication and digital transportation technology, use digital technology with internet on conference system productions, which make new breakthrough in conference industry. -
Page 7: Product Presentation
Fully Digital Conference System User Manual 2. Product Presentation 2.1 Fully Digital Conference Built in Interpretation Chairman/Delegate Unit(With 4.3 Inch Capacitance Color Screen ) 2.2 Features 1. Microphone uses 48 KHZ sampling rate, the sound quality is higher than CD, clear and bright.with DSP audio processing inside, there is no 'poop-poop low-frequency impact sound. -
Page 8: Product Function Introduction
Fully Digital Conference System User Manual 2.3 Product Function Introduction TS-0205(Chairman Unit)： TS-0205A(Delegate Unit)： ① ② ③ ④ ⑤ ⑥ ⑦ ① 4.3” capacitance touch screen ② Chairman Unit Microphone key (touch style) Chairman Unit Microphone priority key(touch style) Delegate Unit Microphone Key (touch style) -
Page 9: Conference Unit Ts-0205/0205A Operating Instructions
Dimension 206×174.2×65.5mm Installation way Tabletop 3. Conference Unit TS-0205/0205A Operating Instructions 3.1 Start up Open the power of host to start the conference system, the unit screen displays "System Loading ...", start page is as follows After starting up, the touch screen display LOGO interface, if the machine does not work normally, you can not switch to the LOGO interface automatically . -
Page 10: Unit Type
Fully Digital Conference System User Manual 3.2 Unit Type The chairman unit has a microphone key and a priority key, the touch screen can switch microphone, close all delegate microphone, switch between Chinese and English, channel switching, volume adjustment, brightness adjustment, service request, initiate sign-in and vote, respond to check-in and vote and other operations. -
Page 11: Sign In
Fully Digital Conference System User Manual Pressing the priority button of the chairman units, and all the mics of delegate units are closed. The mic of chairman units are open. Delegate Unit appears as follows: 3.4 Sign In Go to the menu page of the chair unit, press the start Sign-in button to enter the Sign-in page, then you can see the result of the last time Sign-in. -
Page 12: Channel Selection
Fully Digital Conference System User Manual The PC software can start the five-button election and screen will show as below, press the corresponding button to select the option. The PC software initiates the 5-button rating display as follows, and presses the corresponding button to select the result. -
Page 13: Fire Alarm
Fully Digital Conference System User Manual 3.7 Fire alarm When the host sends out a fire alarm message, the unit will display a "fire warning" prompt, the red light will blink until the host to cancel the fire alarm, the unit to restore the state before the alarm. In the fire alarm, the key failure. -
Page 14: Menu
Fully Digital Conference System User Manual suddenly It can also proceed to broadcast the nameplate function for single or multiple unit. It can save data when power be cut suddenly.the message can not over 8 Chinses word or 16 English character. 3.12 Menu Enter the menu page, as shown in the picture below. -
Page 15: Other Functions
Fully Digital Conference System User Manual After you choose the application item, the machine will remind you whether send the application or not. Yes means sent,otherwise back to last move. After sent the application,you can see the corresponding hint in the PC.The unit will also have the corresponding hint. -
Page 16: Appendix
Fully Digital Conference System User Manual Appendix 1. Microphone frequency response curve 2. Microphone cardioid curve... - Page 17 Fully Digital Conference System User Manual Fully Digital Conference System Version 0.4...
