Summary of Contents for ITC TS-0204
- Page 1 Fully Digital Congress System User Manual TS-0204 TS-0204A Before using this system, please read this manual carefully...
- Page 2 Notice: This manual is only used as the operation instructions of users, not for the maintenance service. After issuing, if any changes of functions or related data, will offer additional explanation, please ask the supplier for more details. This manual belongs to its manufacturer’s copyright, without permission, any agent or person cannot take parts of manual or all contents as a business purpose.
- Page 3 ● This equipment is only used in AC ~220V/50Hz. ● Because of the continuously upgrading appearance, functions, the details please subject to the entity and this manual final interpretation authority belongs to ITC. - 3 -...
-
Page 4: Table Of Contents
CONTENTS Contents...............................4 1. System introduction..........................5 1.1 System Description........................5 1.2 System connection diagram...................... 5 2. Product Description..........................6 2.1 Function Features........................6 2.2 Each part function introduction ....................7 2.3 Main technical parameters......................7 3. Operating instructions ......................... 8 3.1 Power on............................8 3.2 Unit Type............................ -
Page 5: System Introduction
1. System Introduction 1.1 System Description Full digital conference system adopts the ITC original with completely independent intellectual property rights of network communication and digital transmission processing technology, digital technology and network technology was applied to conference system products, so it have a new breakthrough changed in the conference field. -
Page 6: Product Description
2. Product Description TS-0204 is chairman unit, TS-0204A is delegate unit, it has the function of discussion, vote, IC card attendance, video tracking. Delicate and elegant desktop type, very modernize design. Have a key, a vote and IC card inserted into the interface, 4.3 inch TFT true color touch screen, the... -
Page 7: Each Part Function Introduction
2.2 Various parts of products introduction ① Registration card slot port. ② headset microphone port. ③ headphone output. ④ 4.3 inch touch screen. ⑤ Microphone on behalf of unit key. ⑥ chairman unit microphone on the key. ⑦ chairman unit microphone priority button. Main technique parameters Microphone type: Heart-shaped directivity electret Directional 0°/180°: >20dB... -
Page 8: Operating Instructions
3. TS-0204/0204A Operation Manual 3.1 Booting Power on the host system to start the meeting, unit machine screen display "System Loading ...", the start up page as follows. After completion of the boot LOGO interface touch screen display, if the machine is not normal, you can not automatically switch to LOGO interface. -
Page 9: Sign In
Chairman of the machine at this time are shown below. Then press the button to agree or disagree, on behalf of the application is turned on or off according to the FIFO mode. The number of full prompt the user when the number of applicants is full. In NORMAL mode, exceed the number of delegate units will go into a wait state. -
Page 10: Vote
Chairman unit sign control interface Chairman unit menu Interface At this point you can view on the touch screen display and has not yet reached the number of attendance numbers, you can also initiate attendance by PC software. At this point you can select by pressing the microphone key unit machine, press the "sign"... -
Page 11: Channel Selection
PC software can be launched five key election, press the corresponding button, select a result, as shown in the figure below: PC software can be launched five key rating, press the corresponding button, select a result, as shown in the figure below: 3.6 Channel selection Chairman unit and delegate unit on the page icon LOGO channel switching... -
Page 12: Chinese-English Switch
button to enter Chinese-English switch pages, power-down save. Settings page is as follows: 3.9 Timing speech and speech timekeeping This function need to switch controlled by the PC software, please refer to the PC user manual. Its function is to switch the phone, in the timing speech, PC issued regularly speak of time, the unit will display the countdown time remaining presentation, the time to automatically shut down after phone, timing speech only for the delegate unit effectively, the chairman of the unit is invalid;... -
Page 13: Screen Brightness Adjustment
3.13 Screen brightness adjustment Chairman unit enter the menu page, click on "Brightness Adjustment" button to adjust the screen brightness chairman unit, the screen brightness adjustment range of chairman unit is: 0 to 64; brightness adjustment delegate directly unit icons in the lower right corner of the page LOGO chairman unit brightness adjustment delegate 3.14 volume adjustment function All units of volume adjustment buttons are available on the bottom of the page LOGO... - Page 14 Full Digital Congress System VersionV0.1...
