  • Page 1 Digital infrared speech distribution system User Manual TS-0670H-16/0670HS/0670HC TS-0670HD/0670HY Before using the system, please read this manual first...
  • Page 2: Important Instruction

    Important Instruction warning To ensure the safety and reliability of equipment and personnel during the process of installation, use and maintenance, please observe the following items: If you find out any of the following unusual situation during the using process, please ●...
  • Page 3: Table Of Contents

    About digital infrared voice distribution system............... - 4 - 2. Function Introduction........................- 5 - 2.1 TS-0670H-16 16 Channel Digital Infrared Wireless Conference System Controller..- 5 - 2.2 TS-0670HS IR Radiator....................... - 8 - 2.3 TS-0670HD IR Receiver....................- 10 - 2.4 TS-0670HC Battery Charger....................- 12 -...
  • Page 4: Digital Infrared Voice Distribution System Overview

    1. Digital infrared voice distribution system overview About digital infrared voice distribution system Digital infrared voice distribution system adopts a full digital modulation and demodulation technology. In the conference simultaneous interpretation system, the interpreters simultaneously interpret the original sound of the speaker and the translated language will be transmitted through infrared ray in the venue.
  • Page 5: Function Introduction

    2. Function Introduction 2.1 TS-0670H-16 16 Channel Digital Infrared Wireless Conference System Controller TS-0670H series digital infrared emission host is the core part of the digital infrared voice distribution system. With fully digital DQPSK modulated transmission and digital audio compression coding system, it can transmit the 16 channels languages at the same time.
  • Page 6 Product Parts function introduction 1. Zero channel to 15 channel audio signal indicator, light on means have signal, light off means no signal or signal weak. 2. Network work indicator light. Flashing when connected with Interpreter unit or the fully digital conference system well; Light Off when no connection or connection breakdown.
  • Page 7 Specification Model TS-0670H-16 Power Supply ~100-240V 50-60Hz Power rating Carrier frequency 2M - 6 MHZ FM output HF range 2 VPP The biggest audio input range 4 VPP FM output interface BNCx4 Audio input interface RCAx16 RF output impedance 75Ω...
  • Page 8: Ts-0670Hs Ir Radiator

    2.2 TS-0670HS IR Radiator TS-0670HS IR radiator is a high-power infrared radiation device for receiving the carrier signal from the infrared wireless conference controller, and transmitting the carrier signal via infrared. It supports hand in hand connection, support up to 30 radiators to be connected simultaneously.
  • Page 9 Product Features Introduction 1. High / low power transmission or normal power transmission. 2. The DQPSK modulation signal input-output interfaces, to connect modulated signal from infrared controller 3. The DQPSK modulation signal input- output interfaces, to connect IR radiator or dummy load (to increase stability by using a dummy load at end of the line) 4.
  • Page 10: Ts-0670Hd Ir Receiver

    2.3 TS-0670HD IR Receiver TS-0670HD using the latest electronic technology, use of specialized chips, to ensure the best performance and the longest battery life, according to the ergonomic design of the infrared receiver, infrared signal can be well received. Having a channel selection and volume adjustment function, power switch control the battery power, signal indicator, when no signal is received for 5 minutes or unplug the headset receiver 30 seconds, it will automatic turn off, energy saving and environmental protection.
  • Page 11 10. Within the effective range of the infrared radiation receiving unit, no limited to increase the IR receive number. 11. When the receiver cannot receive the signal for five minutes, it will automatic turn off. 12. Unplug the headphones, or not connect the headphones for 30 seconds, it will automatic turn off.
  • Page 12: Ts-0670Hc Battery Charger

    Quality).  5.Max SNR ﹥80dB  6. THD <1%  7.Rated Power: 100mW  8.Standby Power: 8mW  9.Size: 58x 176x 32mm  10.Weight: 0.23Kg(not including batteries) 2.4 TS-0670HC Battery Charger TS-0670HC battery charger is used to recharge IR receiver , Normal power indicator lights in Red;If power indicator lights in Orange,it means under charging;...
  • Page 13 Product Functions Introduction 1. 30nos Receiver Charging Sockets 2. Power Switch 3. Power supply cable box 4. Power Output Socket 5. Power Input Socket(AC 100-240V) Main Technical Parameters  1.Power: AC 100V-240V  2.Max Power: 100W  3.Standby power consumption: 17W ...
  • Page 14: Ts-0670Hy Interpreter Unit

    2.5 TS-0670HY Interpreter Unit TS-0670HY is a functional fully digital conference system Interpreter Unit, it is the equipment which the interpreter use it to translate the speaker's speech at the meeting into different national language.It has built-in speakers and pluggable mi rod, and earphone headset jack, etc.
  • Page 15 9. With cough elimination function. 10. With voice speed remind function (SLOW). 11. Ask for help function. 12. Support headset microphone and Mi pole microphone pickup 13. With speech timing function (charge according to the time) 14. 15 kinds of languages can be translated at the same time, an interpreter room can installed within 6 translation units.
  • Page 16: System Connection Diagram

     Sensitivity: -46 dBV/Pa  Signal to noise ratio: >80dB  THD :<0.1%  The output frequency response: 125Hz~12.5KHz  Maximum power consumption: 7W  The headset load: 16Ω  The headset volume: Max 40mW  Headphone output interface: 3.5mm Mono jack ...
  • Page 17 1. Install the host in a standard rack , the radiation panel is installed in the corner of the room, as far as possible to keep radiation to the every corner. 2. Open the interpreter unit and turn off the microphone stem to listen the original sound;...
  • Page 18: Infrared System Installation Notes

    4. Infrared System Installation Notes Infrared simultaneous interpretation system is easy to install (installation time depends on the radiator positioning and calibration ), simply connect the device directly, without excessive cable arrangement. The maintenance of receiver is only charging. Once installed, the system can be extended at any time. If the size of meeting to expand, simply increase the number of receivers, the basic structure of the system remains unchanged.
  • Page 19: The Effect Of Radiation Panel And Seat Arrangement

    Figure 4-1-2 Coordinate direction schematic of radiation panel 4.2 The effect of radiation panel and seat arrangement If precise alignment of the receiver and the radiation panel, you can receive the best transmission signal.If the radiation panel or receiver out of the optical axis, the received energy will decline.
  • Page 20 radiation panel installation. Apparently, we should be more tend to install radiation panel as figure 4-2-2 showed. But in fact, project installation is very hard to fully achieve the effect of reception and emission like figure 4-2-2, at this time we need to properly use reflection signals to complete signal coverage.
  • Page 21: The Surface Of Wall, Ceiling, Floor And Curtain

    Figure 4-2-4 height can reduce obstruction 4.3 The surface of wall, ceiling, floor and curtain Infrared ray is just like visible light, which can be reflected by bright and smooth surface, but be absorbed by dark and rough surface. The reflected light usually has a positive effect in signal transmission, and will not cause any destructive effect.
  • Page 22: The Coverage Range Of Ir Radiator

    4.4 The coverage range of IR radiator In the system, the coverage range of IR radiator is decided by carrier number of the radiation controller and the output power of the IR radiator. The coverage range can be enlarged by adding the number of IR radiator. The total radiation intensity of the IR radiator is distributed in the controller according to carrier number.
  • Page 23: Overlapping Area And Multipath Effects

    4.5 Overlapping area and multipath effects Every two IR radiators will bring overlapping area. And the total cover area is possibly large than the sum of two individual IR radiator, which will make radiation intensity greater than the needed one. Schematic diagram of two overlapping IR radiator As the receiver receives the signals from multiple IR radiators, the signals will possibly be offset each other due to time delay difference, or the receiver will not...
  • Page 24 The signal reception rate of dark area will not decrease to 0 when the IR radiators are installed in a very high place. The reason of that is because infrared light can be refracted (identical with visible light). So, it will show in the shadow area as the form of diffused light.
  • Page 25: Wire Connection Of Radiation Panel

    Infrared cover diagrams in blind spot situation 4.7 Wire connection of radiation panel Due to different distance from each radiation panel to radiation host, the signal delay will be different. In order to avoid blind spot, installer could symmetrically install the radiation panel with same length cables.
  • Page 26: Rectangular Floor Area

    Symmetrical connect way(It should be advocated.) 4.8 Rectangular floor area How many radiation panels could cover the venue 100%, which could only be decided by field test. But user can use “insurance rectangular floor area”to have a fairly close estimate. Picture 4-8-1 and 4-8-2 illustrate the “rectangular floor area”.
  • Page 27: Installation Of Radiation Panel

    Picture 4-8-2 Typical rectangular floor area by 90 degree 4.9 Installation of radiation panel Infrared radiation panel can be mounted on the wall or ceiling. It is packed with a mounting bracket and screws. Installation as shown below: Notice: Before installation, user need to make sure the air flow around panel to avoid overheating phenomenon.
  • Page 28 will be multiplied by 25ns, so you can adjust the delay time from 25ns to 2475ns (99X25). If the cable directly is connected to the transmission controller, there is no need to consider the cable signal delay. In this case, we just need adjust the time delay switch to be "00", and confirm if need signal delay compensation.
  • Page 29: Control And Indication

    4.11 Control and Indication ◆ 2 Delay Compensation buttons, to compensate for different cable lengths between the transmission controller and radiator. 4.12 Interconnection ◆ output socket (2XBNC), to connect the transmission controller and cascade to next radiator unit - 29 -...
  • Page 30: Common Fault And Maintenance

    5. Common fault and maintenance The host power supply light off Check the power supply I / O switch if it close or open, the equipment power input if well- connected.. A, There are two characters "O" and "I"on the switch power button, when the "O" subsidence, "I"...
  • Page 31 B. Light off during charging,check whether the battery in the receiver is installed correctly. Also check if the receiver temperature anomaly, well connected, or full charged. no voice for Interpreter machine ⒍ A. Check the interpreter machine if is power on B.
  • Page 32 Digital infrared speech distribution system Version 0.4...
