Altronix TROVE AMAG M4000 Installation Manual page 4

1. Align the AMAG M4000 modules on the backplane to match the boards' mounting holes with corresponding pems.
2. Fasten spacers (provided) onto metal pems (Fig. 3a, pg. 4).
3. Mount AMAG M4000 modules to spacers utilizing pan head screws (provided) (Fig. 3a, pg. 4).
4. Fasten TAG2 backplane to Trove2 enclosure utilizing hardware (provided).
Fig. 3
Altronix - eFlow104NBV
Altronix - eFlow104NB
L G N
IN GND IN GND IN GND IN GND IN GND IN GND IN GND IN GND
5
1 2 3 4
F1 F2 F3 F4 F5
Altronix - ACM8
NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM
OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4
TRIGGER
INPUT
IN GND IN GND IN GND IN GND
1 2 3 4
LED1 LED2 LED3 LED4
NC C NO COM NC C NO COM NC C NO COM
OUTPUT 1 OUTPUT 2 OUTPUT 3
Altronix - PDS8
Out8
<1 off 2>
Out7
<1 off 2>
Out6
<1 off 2>
VR6 is mounted
Out5
<1 off 2>
Out4
<1 off 2>
Out3
<1 off 2>
Out2
<1 off 2>
Out1
<1 off 2>
IN2 Fuse
+ INP1 -- + INP2 --
- 4 -
T2AGK7F12V: Configuration of AMAG M4000 Modules:
FACP
TRIGGER
TRG
INPUT
6 7 8
F6 F7 F8
O N O N O N O N
1 1 2 2 3 3 4 4 1 1 2 2 3 3 4 4
MAIN
10A 250V
OUTPUT 5 OUTPUT 6 OUTPUT 7 OUTPUT 8
TRG
Altronix
ACM4
MAIN
NC C NO COM
OUTPUT 4
under PDS8
AMAG - M4000
AMAG - M4000
AMAG - M4000
Pan Head
Screw
Fig. 3a
Pem
Spacer
AMAG M4000 Backplane
Module
