Altronix TROVE AMAG M4000 Installation Manual page 3

1. Align the AMAG M4000 modules on the backplane to match the boards' mounting holes with corresponding pems.
2. Fasten spacers (provided) onto metal pems (Fig. 2a, pg. 3).
3. Mount AMAG M4000 modules to spacers utilizing pan head screws (provided) (Fig. 2a, pg. 3).
4. Fasten TAG2 backplane to Trove2 enclosure utilizing hardware (provided).
Fig. 2
Altronix - eFlow6NB
Altronix - eFlow6NBV
AC1
L G N
IN GND IN GND IN GND IN GND IN GND IN GND IN GND IN GND
5
1 2 3 4
F1 F2 F3 F4 F5
Altronix - ACM8
NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM
OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4
PWR1 + OFF
IN1 Fuse
IN1
10
IN2
Altronix - PDS8
10
P
OUT1 OUT2 OUT3 OUT4
COM ---
N
PWR2 +
1 2 3
Common Power Outputs (NEG)
Altronix VR6 is mounted under PDS8
Trove AMAG M4000 V Kits Installation Guide
T2AGK3F8V: Configuration of AMAG M4000 Modules:
OFF - 24V
ON - 12V
AC DC
NC C NO NC C NO TRIGGER EOL NO GND
+AUX-
SUPERVISED RESET
AC FAIL BAT FAIL
FACP
TRIGGER
TRG
INPUT
6 7 8
F6 F7 F8
O N O N O N O N
1 1 2 2 3 3 4 4 1 1 2 2 3 3 4 4
MAIN
10A 250V
OUTPUT 5 OUTPUT 6 OUTPUT 7 OUTPUT 8
PWR1 +
OUT5 OUT6 OUT7 OUT8
COM ---
PWR2 +
4 5 6 7 8
AMAG - M4000
AMAG - M4000
Pan Head
Screw
Fig. 2a
Pem
Spacer
AMAG M4000 Backplane
Module
