Setting up the monitor
Connecting the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for the stand that was shipped with your monitor. If you are attaching a
stand that you purchased from any other source, follow the setup instructions that were included with the stand.
To connect the monitor stand:
1.
Align and place the stand riser on the stand base.
2.
Open the screw handle at the bottom of the stand base and turn it clockwise to secure the stand assembly.
3.
Close the screw handle.
4.
Open the protective cover on the monitor to access the VESA slot on the monitor.
NOTE: Before connecting the stand assembly to the display, ensure that the front flap is opened to allow space for the assembly.
Setting up the monitor
24
Figure 14. Connecting the stand
Figure 15. Open the protective cover
