Preset display modes
Table 7. HDMI preset display modes (4K mode)
Display mode
IBM 720 x 400
IBM 640 x 480
VESA 640 x 480
VESA 800 x 600
VESA 800 x 600
VESA 1024 x 768
VESA 1024 x 768
VESA 1152 x 864
VESA 1280 x 800
VESA 1280 x 1024
VESA 1280 x 1024
VESA 1600 x 900
VESA 1680 x 1050
VESA 1920 x 1080
VESA 1920 x 1080
VESA 1920 x 1080
VESA 1920 x 1080 (overclock)
VESA 1920 x 1080 (overclock)
VESA 1920 x 1080 (overclock)
VESA 1920 x 1200
VESA 2560 x 1440
VESA 2560 x 1440
VESA 2560 x 1440
VESA 2560 x 1440 (overclock)
VESA 2560 x 1440 (overclock)
VESA 2560 x 1440 (overclock)
VESA 3840 x 2160
VESA 3840 x 2160
VESA 3840 x 2160
VESA 3840 x 2160
VESA 3840 x 2160 (overclock)
VESA 3840 x 2160 (overclock)
VESA 3840 x 2160 (overclock)
Table 8. DisplayPort preset display modes (4K mode)
Display mode
IBM 720 x 400
IBM 640 x 480
VESA 640 x 480
VESA 800 x 600
VESA 800 x 600
VESA 1024 x 768
VESA 1024 x 768
VESA 1152 x 864
VESA 1280 x 800
VESA 1280 x 1024
VESA 1280 x 1024
VESA 1600 x 900
VESA 1680 x 1050
VESA 1920 x 1080
VESA 1920 x 1080
Horizontal frequency
(kHz)
31.47
31.47
37.50
37.88
46.88
48.36
60.02
67.50
49.7
64
80
60
65.29
67.50
137.26
192.788
199.159
205.529
212.019
75
88.787
182.996
257.169
265.625
274.173
282.537
135.00
274.438
333.188
385.75
398.438
411.25
423.875
Horizontal frequency
(kHz)
31.47
31.47
37.50
37.88
46.88
48.36
60.02
67.50
49.7
64
80
60
65.29
67.50
137.26
Vertical frequency
Pixel clock
(Hz)
(MHz)
70
28.322
60
25.175
75
31.50
60
40
75
49.50
60
65
75
78.75
75
108
60
83.50
60
108
75
135
60
108
60
146.25
60
148.50
119.98
285.50
164.917
401
169.931
414.250
174.918
427.5
179.982
441.0
60
162
59.951
241.5
119.998
497.75
164.958
699.5
169.946
722.5
174.967
745.75
179.96
768.5
60.00
594
119.999
1097.75
143.988
1332.75
164.991
1543
169.982
1593.75
175
1645
179.989
1695.5
Vertical frequency
Pixel clock
(Hz)
(MHz)
70
28.322
60
25.175
75
31.50
60
40
75
49.50
60
65
75
78.75
75
108
60
83.50
60
108
75
135
60
108
60
146.25
60
148.50
119.98
285.50
Sync polarity
(Horizontal/Vertical)
-/+
-/-
-/-
+/+
+/+
-/-
+/+
+/+
+/+
+/+
+/+
+/+
+/+
+/+
+/-
+/-
+/-
+/-
+/-
+/+
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
+/-
Sync polarity
(Horizontal/Vertical)
-/+
-/-
-/-
+/+
+/+
-/-
+/+
+/+
+/+
+/+
+/+
+/+
+/+
+/+
+/-
