O PE RATI NG I NSTRU CTI O NS
LXRH, LXRC
Three-wire: IO-Link, transistor, 4 ... 20 mA (active)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LXRH and is the answer not in the manual?

Questions and answers

Related Manuals for SICK LXRH

Summary of Contents for SICK LXRH

  • Page 1 O PE RATI NG I NSTRU CTI O NS LXRH, LXRC Three-wire: IO-Link, transistor, 4 … 20 mA (active)

  • Page 2: Legal Information

    Legal information This publication is protected by copyright. The resulting rights remain with SICK AG. Reproduction of the publication or parts thereof is only permitted within the limits of the statutory provisions of copyright law. Any modification, abridgement or translation of the publication without the express written consent of SICK AG is prohibited.

  • Page 3: Table Of Contents

    Status messages according to NE 107 ................28 Treatment of measurement errors .................. 30 Return of devices ......................33 10 Dismounting and disposal ....................34 10.1 Dismount device ......................34 LXRH, LXRC • Three-wire: IO-Link, transistor, 4 … 20 mA (active)
  • Page 4 11.4 NAMUR recommendations .................... 35 12 Supplement ..........................37 12.1 Technical data ........................ 37 12.2 Dimensions ........................43 12.3 Licences ......................... 44 12.4 Trademark ........................44 Editing status: 2024-06-11 LXRH, LXRC • Three-wire: IO-Link, transistor, 4 … 20 mA (active)

  • Page 5: About This Document

    1 About this document About this document Function This instruction provides all the information you need for mounting, connection and setup as well as important instructions for mainte- nance, fault rectification, safety and the exchange of parts. Please read this information before putting the instrument into operation and keep this manual accessible in the immediate vicinity of the device.

  • Page 6: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use LXRH, LXRC is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description".

  • Page 7: Mode Of Operation - Radar Signal

    2 For your safety Mode of operation - Radar signal Country or region specific settings for the radar signals are deter- mined via the mode. The operating mode must be set in the operating menu via the respective operating tool at the beginning of the setup. Caution: Operating the device without selecting the relevant mode constitutes a violation of the regulations of the radio approvals of the respective...

  • Page 8: Product Description

    The SICK Product ID consists of the host name pid.sick.com, the article number (P/N) and the serial number (S/N), each separated by a slash. The SICK Product ID is indicated as text and QR code on the type plate and/or on the packaging. Fig. 2: SICK Product ID (example) Documents and software Further information can be found on our homepage.

  • Page 9: Principle Of Operation

    There you will find the documentation and further information about the device. Principle of operation Application area LXRH, LXRC is a radar sensor for non-contact, continuous level measurement of liquids. Functional principle The instrument emits a continuous, frequency-modulated radar signal through its antenna.

  • Page 10: Storage And Transport Temperature

    Storage and transport temperature see chapter "Technical data - temperature Ambient conditions" • Relative moisture 20 … 85 % Accessories Suitable accessories can be found on the Internet via the SICK Prod- uct ID of the sensor or on www.sick.com.

  • Page 11: Mounting

    4 Mounting Mounting General instructions Ambient conditions The instrument is suitable for standard and extended ambient condi- tions acc. to DIN/EN/BS EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used indoors as well as outdoors. Note: Process conditions For safety reasons, the instrument must only be operated within the permissible process conditions.
  • Page 12 Please keep this in mind when mounting or making changes later. Reference plane The measuring range of the LXRH, LXRC physically begins with the antenna end. However, the min./max. adjustment begins mathematically with the reference plane, which is located differently depending on the sensor version.
  • Page 13 4 Mounting the vessel wall is expected. In such cases, we recommend repeating the false signal suppression at a later date with existing buildup. > 200 mm (7.87") Fig. 5: Mounting of the radar sensor on round vessel tops In vessels with conical bottom it can be advantageous to mount the device in the centre of the vessel, as measurement is then possible down to the lowest point of the bottom.
  • Page 14 Fig. 8: Thread mounting If the reflective properties of the medium are good, you can mount LXRH, LXRC on sockets longer than the antenna. The socket end should be smooth and burr-free, if possible also rounded. You will find recommended values for socket heights in the following illustration or the tables.
  • Page 15 4 Mounting The mounting location of the radar sensor should be a place where no Vessel installations other equipment or fixtures cross the path of the radar signals. Vessel installations, such as e.g. ladders, limit switches, heating spi- rals, struts, etc., can cause false echoes and impair the useful echo. Make sure when planning your measuring point that the radar sensor has a "clear view"...
  • Page 16 4 Mounting Fig. 12: Agitators Through the action of filling, stirring and other processes in the vessel, Foam generation compact foams which considerably damp the emitted signals may form on the medium surface. Note: If foams lead to measurement errors, you should use the biggest pos- sible radar antennas or as an alternative, sensors with guided radar.

  • Page 17: Connecting To Power Supply

    5 Connecting to power supply Connecting to power supply Preparing the connection Safety instructions Always keep in mind the following safety instructions: • Carry out electrical connection by trained, qualified personnel authorised by the plant operator • If overvoltage surges are expected, overvoltage arresters should be installed Warning: Only connect or disconnect in de-energized state.

  • Page 18: Wiring Plan

    5 Connecting to power supply Wiring plan M12 x 1 plug out 1 out 2 Fig. 13: Wiring plan - Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor) Voltage supply PNP switching NPN switching Current output Contact, plug connector Function/Polarity Voltage supply/Plus Transistor output 2 or current output Voltage supply/Minus Transistor output 1 or IO-Link port Switch-on phase After switching on, the device first carries out a self-check:...

  • Page 19: Access Protection

    6 Access protection Access protection Bluetooth radio interface Devices with a Bluetooth radio interface are protected against un- wanted access from outside. This means that only authorized persons can receive measured and status values and change device settings via this interface. Bluetooth access code A Bluetooth access code is required to establish Bluetooth communi- cation via the adjustment app of the end device (smartphone/tablet).

  • Page 20: Setup With Smartphone/Tablet (Bluetooth)

    7 Setup with smartphone/tablet (Bluetooth) Setup with smartphone/tablet (Bluetooth) Preparations System requirements Make sure that your smartphone/tablet meets the following system requirements: • Operating system: iOS 13 or newer • Operating system: Android 5.1 or newer • Bluetooth 4.0 LE or newer Download the adjustment app from the "Apple App Store"...

  • Page 21: Parameter Adjustment

    7 Setup with smartphone/tablet (Bluetooth) If the Bluetooth connection is interrupted, e.g. due to a too large distance between the two devices, this is displayed on the adjustment tool. The message disappears when the connection is restored. Change device code Parameter adjustment of the device is only possible if the parameter protection is deactivated.

  • Page 22: Menu Overview

    8 Menu overview Menu overview Adjustment app Start image Device information Actual measured values Device status Device name, software version, Filling height, distance, measurement relia- OK, error indication serial number bility, electronics temperature, meas. rate etc. Basic functions Menu item Submenu Selection Setup...
  • Page 23 8 Menu overview Menu item Selection Adjustment options Output Transistor function (P-N) pnp, npn Function output 2 (OU2) Switching output (SSC 1.2) Current output: 4 … 20 mA Function current output ≤ 3.6 mA ≥ 21 mA Last valid measured value Adjustment with medium Switching output selection Output 1 (SSC 1.1)
  • Page 24 8 Menu overview Menu item Selection Adjustment options Mode Mode 1: EU, Albania, Andorra, Azerbaijan, Mode 1 Australia, Belarus, Bosnia and Herzegovina, Mode of operation 2 Canada, Liechtenstein, Moldavia, Monaco, Mode 3 Montenegro, New Zealand, Northern Mac- edonia, Norway, San Marino, Saudi Arabia, Serbia, South-Africa, Switzerland, Turkey, Ukraine, United Kingdom, USA Mode of operation 2: Brazil, Japan, South...

  • Page 25: Explanation Special Parameters

    8 Menu overview Menu item Selection Adjustment options Sensor information Device name, order number, serial number, hardware/software version, factory calibra- tion Sensor characteristics Sensor features from order text Explanation special parameters SP01 - Activate measur- Measuring range start limiting is activated here. The appropriate ing range start limiting distance value is set in the special parameter SP02.
  • Page 26 8 Menu overview → Up to this value, a relatively weak reflection signal of the medium is thus output as a measured value. SP25 - Adjustment Here you can switch over if the adjustment and the measured value output is carried out in "Distance" or "Filling height".

  • Page 27: Diagnostics And Servicing

    9 Diagnostics and servicing Diagnostics and servicing Maintenance Maintenance If the device is used properly, no special maintenance is required in normal operation. Precaution measures In some applications, buildup on the antenna system can influence against buildup the measuring result. Depending on the sensor and application, take measures to avoid heavy soiling of the antenna system.

  • Page 28: Status Messages According To Ne 107

    9 Diagnostics and servicing Error Cause Rectification 4 … 20 mA signal not stable Fluctuating measured value Set damping 4 … 20 mA signal missing Electrical connection faulty Check connection, correct, if necessary Voltage supply missing Check cables for breaks; repair if nec- essary Operating voltage too low, load resist- Check, adapt if necessary...
  • Page 29 9 Diagnostics and servicing and explained by pictographs: Fig. 16: Pictographs of the status messages Failure - red 2 Out of specification - yellow 3 Function check - orange Maintenance required - blue Malfunction (Failure): Due to a malfunction in the instrument, a fault signal is output. This status message is always active.

  • Page 30: Treatment Of Measurement Errors

    9 Diagnostics and servicing Code Cause Rectification Text message F111 Switching point 1 is smaller than switch- Select switching point 1 to greater than ing point 2 switching point 2 Switching points inter- changed Function check Code Cause Rectification Text message C700 A simulation is active Finish simulation...
  • Page 31 9 Diagnostics and servicing time Real level Level displayed by the sensor Note: If the output level is constant, the cause could also be the fault setting of the current output to "Hold value". If the level is too low, the reason could be a line resistance that is too high Liquids: Measurement error at constant level Fault description...
  • Page 32 9 Diagnostics and servicing Fault description Cause Rectification Measured value jumps to- The level echo cannot be distinguished In case of interferences due to instal- wards 0 % during filling from the false signal at a false signal po- lations in the close range: Change sition (jumps to multiple echo) polarisation direction Chose a more suitable installation po-...

  • Page 33: Return Of Devices

    9 Diagnostics and servicing Return of devices Do not return devices without consulting SICK service. Note: For efficient processing and a quick determination of the cause, please enclose the following with the return: • Details of a contact person •...

  • Page 34: Dismounting And Disposal

    10 Dismounting and disposal 10 Dismounting and disposal 10.1 Dismount device 1. Switch off operating voltage for the device. 2. Disconnect all connection cables from the device. 3. If the device is to be replaced, mark the position and orientation on the bracket or the surrounding area.

  • Page 35: Certificates And Approvals

    The corresponding certificates can be found on our homepage. 11.3 Conformity On www.sick.com you can find conformity declarations, certificates and current operating instructions of the product. For this purpose, enter the article number of the product in the search field (article num- ber: see type plate entry in the field "P/N"...
  • Page 36 11 Certificates and approvals For further information see www.namur.de.

  • Page 37: Supplement

    12 Supplement 12 Supplement 12.1 Technical data Note for approved instruments The technical data in the respective safety instructions which are included in delivery are valid for approved instruments (e.g. with Ex approval). These data can differ from the data listed herein, for example regarding the process conditions or the voltage supply.
  • Page 38 12 Supplement IO-Link communication readiness 20 mA 4 mA ≤ 3,6 mA Fig. 17: Run-up time and measured value output Run-up time Measured value output Off Output variable - three-wire 4 … 20 mA Output signal 4 … 20 mA (active) Connection technology Three-wire Range of the output signal...
  • Page 39 12 Supplement Inverse current NPN < 25 µA Function Ʋ Output 1 Switching output or IO-Link Ʋ Output 2 Swithching output or 4 … 20 mA (active) Output variable - Three-wire IO-Link Output signal IO-Link acc. to IEC 61131-9 Dynamic behaviour output Reaction time transistor output with ≤...
  • Page 40 12 Supplement 10 mm (0.3937 in) 2 mm (0.079 in) - 2 mm (- 0.079 in) 0 0,25 m (0.8202 ft) - 10 mm (- 0.3937 in) Fig. 18: Deviation under reference conditions Reference plane Antenna edge Recommended measuring range Characteristics and performance data Measuring frequency W-band (80 GHz technology)

  • Page 41: Process Conditions

    (32 °F) 80 °C 130 °C (176 °F) (266 °F) Fig. 19: Temperature derating LXRH, LXRC Process temperature Ambient temperature Sterilization in place (SIP) process temperature After prior Cleaning in place (CIP) cleaning up to max. +80 °C (+176 °F): SIP process temperature with vapour stratification up to Ʋ...
  • Page 42 12 Supplement Indication Status indication LED illuminated ring (green-yellow-red) Adjustment Smartphone/Tablet Adjustment app IO-Link master IODD Voltage supply Operating voltage U 12 … 35 V DC Operating voltage U - IO-Link commu- 18 … 35 V DC nication Max. power consumption Ʋ...

  • Page 43: Dimensions

    ø 32 mm 1 NPT ø 29,5 mm ø 39,9 mm ø 39 mm (1.26") (1.16") (1.57") (1.54") ø 39,9 mm (1.57") Fig. 20: Dimensions LXRH, LXRC Thread G¾, ¾ NPT Thread G1, 1 NPT Hygienic version thread G1 with O-ring...

  • Page 44: Licences

    12 Supplement 12.3 Licences SICK uses open source software that is licensed by the rights holders under the free licences GNU General Public Licence (GPL Version2, GPL Version3) and GNU Lesser General Public Licence (LGPL), MIT Licence, zLib Licence, and licences derived from the BSD Licence.
  • Page 45 Notes...
  • Page 46 Notes...
  • Page 47 Notes...
  • Page 48 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail office@sick.com.gr E-Mail sales.gsg@sick.com Hong Kong Slovakia Phone +852 2153 6300 Phone +421 482 901 201 E-Mail ghk@sick.com.hk E-Mail mail@sick-sk.sk Detailed addresses and further locations at www.sick.com SICK AG | DE-79183 Waldkirch | Germany | www.sick.com 1030068-EN-240619...
