CONTROL BOARD OPERATION
Display
1.DMX Address <001> - <512>
2.DMX Channel <01> <02> <03> <4CW> <4WW>
<08> <11> <12>
3.Dim Mode <01> <02> <03> <04> <05>
4.Static Color R, G, B,C,W, RG, GB, RB, RGB...
5.Manual Color R<000> - <255>
G<000> - <255>
B<000> - <255>
CW<000> - <255>
WW<000> - <255>
Dim<000>- <255>
Str<000> - <100>
6.Manual White WT<01>-<11> Dim<001>-<100>
7. Auto Program <Pr01> - <Pr16>
Sp<000> - <100>
Dim<000> - <255>
8.Sound Mode <Sen:000> - <Sen:100>
9.Master/Slave <M> <S>
10.Temp Temp< xxx >
11.Update
<N>/ <Y>
<START>
12.Reset <N>/<Y>
DMX address
After select the "DMX Address" and press "Enter", then use "Up" and "Down" to set the desired DMX address, press
"Enter" again to confirm.
DMX modes
After select the "DMX Channel" and press "Enter", then use "Up" and "Down" to set the desired DMX mode, press
"Enter" again to confirm.
Dimmer curve
After select the "Dimmer Curve" and press "Enter", then use "Up" and "Down" to set the desired dimmer curve, press
"Enter" again to confirm.
www.event-lighting.com.au
Options / Values Function
Set DMX address
Select DMX channel mode
Select dimmer curve
Select static colour
Set intensity of each colour separately for color mixing
and strobe rate
Set intensity of 11 whites
Select built-in automatic programs, auto run speed and
dimmer level
Select sound active mode and the sensitivity level from
Sen:<000> to Sen:<100>
Select Master/Slave modes
ndicate the current temperature of the driver PCB
I
(Celsius degree)
Select to update firmware
Use this fixture to update another fixture's software
Recover manufactory default
