LED Pixel Bar
PIXBAR12x8
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au
V2.1.0
0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Event Lighting PIXBAR12x8
Summary of Contents for Event Lighting PIXBAR12x8
- Page 1 For safety, please read this user manual carefully before initial use. Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions.
-
Page 2: Table Of Contents
www.event-lighting.com.au CONTENTS Safety Instructions Product Installation Diagrams Control Board Operation Special Chaser Mode DMX Values Technical Specifications Warranty... -
Page 3: Safety Instructions
www.event-lighting.com.au Safety Instructions WARNING • Do not open this device, there is no user-serviceable parts inside. Risk of electric shock. • Do not look at the light source when the device is on. • CAUTION: This unit's housing may be hot during and after operation. •... - Page 4 www.event-lighting.com.au Lux Chart Dimensions...
-
Page 5: Control Board Operation
www.event-lighting.com.au CONTROL BOARD OPERATION Display Options / Values Function 01.DMX Address <001> - <512> Set DMX address 02.DMX Channel <03> <04> <06> <08> <09> Select DMX channel mode <12> <16> <24> <48> <50> 03.Dimmer Curve <01> <02> <03> <04> <05> Select dimmer curve 04.Sound Mode Sen:<000>... - Page 6 www.event-lighting.com.au Green + Blue Red + Blue Red + Green Red + Green + Blue Red + White Green + White Blue + White Red + Green + White Red + Blue + White Green + Blue + White RGBW Red + Green + Blue + white Manual Colour mode Entered "Manual Color"...
- Page 7 www.event-lighting.com.au On the master unit, setup the DMX address to the total number of fixtures in the string. For example, you may have a total of 20 par cans including the master, so the DMX address should be set to “20”. On the master unit, go to master/slave menu setting and set the unit to master On the master unit, set the unit to “Auto Mode”...
- Page 8 www.event-lighting.com.au Auto chasing 7 Auto chasing 8 Sound active mode Auto run speed Use preset dimming curve dimmer curve 1 dimmer curve 2 dimmer curve 3 dimmer curve 4 dimmer curve 5 LED1-LED6 Red 0%-100% LED1-LED6 Green 0%-100% LED1-LED6 Blue 0%-100% LED1-LED6 White 0%-100% LED7-LED12 Red 0%-100% LED7-LED12 Green 0%-100%...
- Page 9 www.event-lighting.com.au LED10-LED12 Red 0%-100% LED10-LED12 Green 0%-100% LED10-LED12 Blue 0%-100% LED10-LED12 White 0%-100% LED1-LED2 Red 0%-100% LED1-LED2 Green 0%-100% LED1-LED2 Blue 0%-100% LED1-LED2 White 0%-100% LED3-LED4 Red 0%-100% LED3-LED4 Green 0%-100% LED3-LED4 Blue 0%-100% LED3-LED4 White 0%-100% LED5-LED6 Red 0%-100% LED5-LED6 Green 0%-100% LED5-LED6 Blue 0%-100% LED5-LED6 White 0%-100%...
- Page 10 www.event-lighting.com.au LED4 Blue 0%-100% LED4 White 0%-100% LED5 Red 0%-100% LED5 Green 0%-100% LED5 Blue 0%-100% LED5 White 0%-100% LED6 Red 0%-100% LED6 Green 0%-100% LED6 Blue 0%-100% LED6 White 0%-100% LED7 Red 0%-100% LED7 Green 0%-100% LED7 Blue 0%-100% LED7 White 0%-100% LED8 Red 0%-100% LED8 Green 0%-100%...
-
Page 11: Technical Specifications
-Software Upgrade via DMX: Yes Housing -Housing Materials: Aluminium Housing -Housing finish: Matte Black -Cooling: Fanless Cooling -Dimension: 1050 x 165 x 80 mm -Net Weight: 4.5 kg WARRANTY Please refer to your local dealer or please contact Event Lighting Pty Ltd Website: www.event-lighting.com.au...
