Introduction Thank you for purchasing the CTS HES-5105SFP+. The HES-5105SFP+ is a Managed CPE Switch that delivers 10G and Multi-Gigabit FTTX solutions to meet modern network requirements, offering an optimal balance of performance and cost- effectiveness. This user's guide primarily introduces the hardware aspects of the HES-5105SFP+ Managed CPE Switch, including its appearance, LED definitions, installation, operation, and maintenance.
1.2 Key Features Interface RJ-45 Port - 1 x 10G/5G/2.5G/1G/100MBase-T RJ-45 - 3 x 2.5G/1G/100MBase-T RJ-45 Fiber Port - 1 x 10/1GBase-X SFP+ Standards - IEEE 802.3 10Base-T - IEEE 802.3u 100Base-TX/FX - IEEE 802.3ab 1000Base-T - IEEE 802.3z 1000Base-X - IEEE 802.3bz 2.5G/5GBase-T (NBase-T) - IEEE 802.3an 10GBase-T - IEEE 802.3az 10GBase-R...
Page 8
Layer 2 Switch Features Port Management - State, Description, Media Type, Port Type, Speed, Duplex and Flow Control VLAN - IEEE 802.1q VLAN VLAN ID: 4094 IDs VLAN Concurrent Groups: 128 VLAN Groups - Port-Based VLAN - Q-in-Q Double tag with Configurable Ether Type (ISP mode) * - QoS based on 802.1p CoS and DSCP - Scheduling Algorithm...
Page 9
Management - SNMP v1, v2c & v3 (Support Traps) - Web (HTTP/HTTPs) - CLI (Telnet/SSHv2) - SNTP with Daylight Saving Time - LLDP* Upgrade/Restore - Firmware Upgrade/Downgrade HTTP/HTTPS/FTP/TFTP DHCP Auto-provision via DHCP Option 60/43 - Configuration Upload/Backup HTTP/HTTPS/FTP/TFTP DHCP Auto-provision via DHCP Option 60/43 - Auto Configure Backup FTP/TFTP ...
Page 10
Dimension & Weight - Size: 180 x 130 x 30mm (W x D x H) - Weight: 380g Standards and Certifications CE/FCC Class B - Safety: EN/IEC 62368-1 - EMC: EN 55032 / EN 55035 - ESD Air Discharge: +/-8kV Contact Discharge: +/-4kV - EFT AC input: +/-1kV...
1.3 Appearance 1.3.1 Front and Rear Panels Figure 1-1. Front Panel of HES-5105SFP+ Figure 1-2. Rear Panels of HES-5105SFP+ The interfaces on the front and rear panels of the switch are described below: A. Power Jack Connector: Compatible with the included power adapter, which has an input of 100-240VAC, 50/60Hz, and an output of 12VDC, 1.5A.
1.3.2 Top Panel Figure 1-3. Top Panel of HES-5105SFP+ The interfaces on the top panel of the switch are described below: E. LEDs Includes Power LEDs of Power, Status, WAN (Link/ACT/Speed), LAN1~LAN4 (Link/ACT/Speed). For more details, please refer to Section 1.4 LED Definitions.
1.3.3 Side Panels Figure 1-4. Side Panel (right) of HES-5105SFP+ Figure 1-5. Side Panel (left) of HES-5105SFP+ The interfaces on the side panel of the switch are described below: F. Reset Button : To restart the system: Press and hold the reset button for more than 5 seconds until the Status LED lights up orange, then release it ...
1.4 LED Definitions The switch is Plug & Play compliant. The real-time operational status can be monitored through a set of LED indicators located on the top panel. Figure 1-5. LEDs of HES-5105SFP+ Color Operation Device is powered down or works abnormally. Power Green Lit when the power is operating normally.
1.5 Cable Specifications The following table contains various cable specifications for the Managed Switch. Please make sure that you use the proper cable when connecting the Switch. Cable Type Description UTP Cat. 5 (100 meters max.) 100Base-TX EIA/TIA-568 150-ohm STP (100 meters max.) UTP Cat.
Installation To properly install the Switch, please follow the procedures listed below. These procedures will be respectively described in detail in the following sections. Installation Requirements Checking the Package Contents Installing the Switch Powering on the Switch ...
2.1 Installation Requirements Basic requirements for installation are as follows: Environmental conditions One power outlet Proper ventilation Proper isolation to electrical noise, radio, etc. UTP cables should not run in the same duct with power and phone line cables ...
2.3 Installing the Switch CAUTION To prevent any damage or failure of the Managed Switch, please DO NOT block the ventilation holes. Use the following guidelines when choosing a place to install the Switch: Firm and steady flat surface. ...
2.5 Connecting the Switch to Network Connect to Network This HES-5105SFP+ has 1 x 10/1Gbps SFP+ slot, 1 x 10G/5G/2.5G/1G/100Mbps RJ-45 port and 3 x 2.5G/1G/100Mbps RJ-45 Port for you to implement it in your environment. The SFP+ slot can be plugged with 10G/1G Base-X SFP/SFP+ Fiber transceiver.
Operation A built-in management module of the Managed Switch provides users flexible interfaces to configure, control and monitor the system remotely and locally. To know the further information about the operation of this switch, please refer to our Network Management User’s Manual for the detailed management functions and required installation and operation procedures.
Maintenance It is easy to use and maintain this Managed Switch. The procedures are suggested when you want to identify faults, perform hardware replacement and firmware upgrading. 4.1 Fault Identification Identifying faults can greatly reduce the time required to find problem and solution. Users may perform local check or remote check to find the problems.
4.2 Hardware Replacement Procedures WARNING! The Managed Switch contains no user-serviceable parts. DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair it. Failure to observe this warning could result in personal injury or death from electrical shock. Failure to observe the above warning will immediately void any Warranty. 4.3 Firmware Upgrade The Managed Switch may require a firmware upgrade when necessary.
