3. Specification

Technical
HDMI Compliance HDMI 2.1
HDCP Compliance HDCP 2.3 / 1.4
Video Bandwidth 48Gbps
Video Resolution
Color Depth
Color Space
HDR
Audio Format
ESD Protection
Connection
Input
Output
Control
Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit,
8K@30Hz 4:4:4 12bit
8/10/12bit
RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0
HDR, HDR10, HDR10+, Dolby Vision, HLG
HDMI input/output:
LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos,
DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master
Audio, DSD
Auido de-embedding output:
Optical: LPCM/Dolby/DTS 5.1CH
Analog: LPCM 2CH
Human body model — ±8kV (air-gap discharge) &
±4kV (contact discharge)
1 × HDMI IN [Type A, 19-pin female]
4 × HDMI OUT [Type A, 19-pin female]
1 × OPTICAL [S/PDIF]
1 × L/R [3.5mm Stereo Mini-jack]
1 × SERVICE [USB Type C, Update port]
