User Manual
PT-SP-HD14-48G
No. Name
CEC DIP
4
switch
EDID DIP
5
switch
6 SERVICE Firmware update port.
7 IN port
OUT port
8
(1~4)
9 OPTICAL
10 L/R
11 DC 5V
Use this DIP switch to enable or disable CEC.
1 - CEC disable: Prevent CEC communication between
source and sink devices.
0 - CEC enable: Allow CEC communication between source
and sink devices.
Use the DIP switch to set EDID.
[DIP]=1111: Copy OUT1 port sink EDID
[DIP]=1110: FRL12G_8K_HDR,2.0CH
[DIP]=1101: FRL12G_8K_HDR,5.1CH
[DIP]=1100: FRL12G_8K_HDR,7.1CH
[DIP]=1011: FRL10G_8K_HDR,2.0CH
[DIP]=1010: FRL10G_8K_HDR,5.1CH
[DIP]=1001: FRL10G_8K_HDR,7.1CH
[DIP]=1000: 4K120(420)_HDR,2.0CH
[DIP]=0111: 4K120(420)_HDR,5.1CH
[DIP]=0110: 4K120(420)_HDR,7.1CH
[DIP]=0101: 4K60(444)_HDR,2.0CH
[DIP]=0100: 4K60(444)_HDR,5.1CH
[DIP]=0011: 4K60(444)_HDR,7.1CH
[DIP]=0010: 1080P120(444)_HDR,2.0CH
[DIP]=0001: 1080P60(444), 2.0CH
[DIP]=0000: Custom EDID Upload
HDMI signal input port, connecting to HDMI source device
such as DVD or PS5 with an HDMI cable.
HDMI signal output port, connecting to HDMI display device
such as TV or Monitor with an HDMI cable.
Optical fiber audio output port, connecting to an audio
output device such as an amplifier. (Max bandwidth: 24.57M)
Analog audio output port, connecting to an audio output
device such as a speaker.
DC 5V/2A Power input port.
Function Description
4
