Package List; Panel Description - PureTools PT-SP-HD14-48G User Manual

User Manual
PT-SP-HD14-48G

1.3 Package List

⚫
1 × 8K HDMI 1x4 Splitter
⚫
1 × 5V/2A Multinational Power Supply
⚫
2 × Mounting Ear
⚫
4 × Machine Screw (KM3*4)
⚫
1 × User Manual

2. Panel Description

1 2
IN
7
No. Name
1 Power LED The power LED lights in red when the device is powered on.
2 IN LED
OUT LED
3
(1~4)
HDCP DIP
4
switch
IN OUT 1 OUT 2 OUT 3 OUT 4
3
OUT 1 OUT 2
8
When the HDMI IN port connects an active source device,
the green LED will be on.
When the HDMI OUT 1/4 port connects a display device and
outputs signal, the corresponding green LED will be on.
Use this DIP switch to set HDCP.
1 - Pass-through mode: The output HDCP follows the source.
0 - Managed mode: If the source has HDCP, the output will
be set to HDCP 1.4; if the source has no HDCP, the output
will be set to no HDCP.
OUT 3 OUT 4
Function Description
3
1 1
0 0
HDCP CEC EDID SERVICE
4
6
5
L/R
9 10 11
