Icom IC-7760 Operating Manual page 9

These instructions describe how to use the HDSDR application with the IC-7760.
L Before reading this guide, read "Preparations for using the IC-7760 with the HDSDR application," which can be downloaded
from the Icom website, for details on how to install the software and connect the IC-7760 to HDSDR.
L These instructions are based on using:
• Microsoft ® Windows
• IC-7760 USB I/Q Package for HDSDR
• HDSDR version 2.80
• CW Skimmer version 2.1
• VB-Audio Hi-Fi Cable version 1.0.3.5
• Null-modem emulator (com0com) version 3.0.0.0
• N1MM Logger+ version 1.0.10502
Table of contents
Starting up HDSDR .................................................................................................................................................... 2
HDSDR Main screen .................................................................................................................................................. 2
A. Using the IC-7760 with HDSDR ............................................................................................................................ 3
D Operation ............................................................................................................................................................. 3
D Settings ............................................................................................................................................................... 3
D Action .................................................................................................................................................................. 3
B. Using HDSDR as a 3rd receiver ........................................................................................................................... 4
D Operation ............................................................................................................................................................. 4
D Settings ............................................................................................................................................................... 5
D Action .................................................................................................................................................................. 5
C. Using CW Skimmer with HDSDR (For a narrow 24 kHz bandwidth) ................................................................ 6
D Operation: Making a call to a station that is decoded in CW Skimmer ................................................................ 6
D Settings: Making a call to a station that is decoded in CW Skimmer .................................................................. 6
D Action: Making a call to a station that is decoded in CW Skimmer ................................................................... 10
D Operation: Making a call to a station that is in Split operation and in a pile up ................................................. 11
D Settings: Making a call to a station that is in Split operation and in a pile up .................................................... 12
D Action: Making a call to a station that is in Split operation and in a pile up ....................................................... 15
D Operation: Checking the CW band in CW Skimmer while communicating in the SSB mode ........................... 16
D Settings: Checking the CW band in CW Skimmer while communicating in the SSB mode .............................. 17
D Action: Checking the CW band in CW Skimmer while communicating in the SSB mode ................................. 20
D Troubleshooting ................................................................................................................................................. 21
D. Using CW Skimmer with HDSDR (For a wide* bandwidth) ............................................................................. 22
D Operation ........................................................................................................................................................... 22
D Settings ............................................................................................................................................................. 23
D Action ................................................................................................................................................................ 27
HDSDR setting notes .............................................................................................................................................. 28
D The Lock function .............................................................................................................................................. 28
D Settings: Receiving mode .................................................................................................................................. 28
IC-7760 I/Q Settings screen .................................................................................................................................... 29
USB Dial Settings screen........................................................................................................................................ 30
Using the RC-28 ....................................................................................................................................................... 30
