Icom IC-7760 Operating Manual page 33

D. Using CW Skimmer with HDSDR (For a wide bandwidth*)
D Settings
CW Skimmer
1. To input I/Q data to CW Skimmer, click <View>
→ <Settings> → the "Radio" tab, and then set the
items as described below.
Hardware Type:
Sampling Rate:
LO Frequency, Hz: The same frequency as the
2. To input the I/Q data and output the demodulated
audio in CW Skimmer to the speaker, click the
"Audio" tab, and then set the items as described
below.
Signal I/O Device: Hi-Fi Cable Output
Audio I/O Device: A speaker connected to your PC
SoftRock
192 kHz
HDSDR Tune frequency.
3. To output the decoded result to N1MM Logger+,
click the <Network> tab, and then set the items as
described below.
Enable Telnet Server: Put a check mark.
Port:
4. Click <OK>.
L If a firewall setting confirmation screen is displayed,
allow access.
25
Default setting (7300) is
recommended.
