Icom IC-7760 Operating Manual page 7

Connecting the IC-7760 to a PC
Connect a USB cable (USB 3.0, User supplied) from the [USB] port on the RF deck's rear panel to one of the PC's
USB ports.
L When you connect a USB cable for the first time, a PC starts installing the driver after turning ON the RF deck and controller.
NOTE:
• Before connecting a USB cable, turn OFF the controller.
• The transceiver may not operate properly if connecting the IC-7760 to a PC through any USB hub.
• Depending on the length of a USB cable, the transceiver may not operate properly even if it is recognized by
the PC. Use as short a cable as possible.
To a USB port
PC with HDSDR installed
D Confirming that the driver has been successfully installed
After the installation has been completed, use the PC's Device Manager to confirm that the driver has been
successfully installed.
1. Right-click the Windows icon, and then click
"Device Manager."
L If "User Account Control" is displayed, click <Yes>.
2. Double-click "Universal Serial Bus controllers,"
and then confirm that "IC-7760 I/Q OUT Port" is
displayed.
NOTE: If "IC-7760 I/Q OUT Port" is not displayed,
the driver may not have been properly installed.
Install the driver again. (pp. 5 ~ 6)
IC-7760 (RF deck)
A/B USB cable (USB 3.0)
7
To the [USB] port
Type B
Confirm
