IC-7760 HDSDR operations
D. Using HDSDR with CW Skimmer (For a wide bandwidth*)
The CW Skimmer application decodes the CW signals received from HDSDR.
Use this when checking the wide band and getting information of many CW stations. This is useful when you
participate in a CW contest.
L The HDSDR's local oscillator frequency (LO) is synchronized with the IC-7760's operating frequency.
L Manually set the same frequency to the HDSDR Tune frequency and the CW Skimmer LO frequency.
Install CW Skimmer (Shareware), VB-Audio Hi-Fi Cable (Donationware), and N1MM Logger+ (Freeware).
IC-7760
DUAL
MAIN
RX 14.100 CW
SUB
RX/TX 7.006 CW
TIP: Each application can be downloaded from the following websites. (As of October 2024)
• HDSDR:
• CW Skimmer (with Omni-Rig):
• VB-Audio Hi-Fi Cable:
• Null-modern emulator (com0com): https://sourceforge.net/projects/com0com/?source=directory
• N1MM Logger+:
L Information
• Icom has checked the operations with these applications but does not guarantee their performance.
• These applications are not Icom products.
• The URL may change without notice or obligation. Check for the latest information.
CI-V
HDSDR
SPLIT
LO
Tune 7.085
I/Q data
LO ≠ TUNE
https://www.hdsdr.de/
https://www.dxatlas.com/Download.asp
https://www.vb-audio.com/Cable/index.htm#DownloadASIOBridge
https://n1mmwp.hamdocs.com/
7.006
VB-Audio
Hi-Fi Cable
4
* Approximately 170 kHz
CW Skimmer
7.015
AF
LO=7.085
Telnet
N1MM
Logger+
Call sign
List
(Band map)
