3. Installation
3.1 Installation Overview
A complete working system consists of the fibre laser source, the laser arm with the galvanometer lens, a computer (not
included) with engraving software (included), and all applicable connection cables. A support column and workbed
come included to assist your work. Users can also configure other additional accessories (such as a rotary axis) to suit
their needs.
Use only the hardware, wiring, and power sources that came with or are compatible with this device.
Installing equipment that your device is not designed to work with can lead to poor performance,
shortened service time, increased maintenance costs, property damage, and personal injury.
Please note the specific requirements of your system's installation. Every customer must understand these notes before
installation to execute a proper setup and achieve safe laser performance. If you have any installation questions or
problems, contact our technicians and customer support team.
Any auxiliary equipment must be adjusted to the base machine. Queries may be directed to the dealer or manufacturer
of such equipment.
3.2 Location Selection
Prior to assembling your fibre laser marker, select an appropriate location for its use.
Be sure that it meets all of the requirements discussed in the Safety Information above. The location should be stable,
level, dry, and climate controlled to ensure an ambient temperature 5–35°C and an ambient humidity under 70%. In
particular, the temperature and humidity together should not be close to the dew point. It is also advisible to use a
windowless room or to use blinds and/or curtains to avoid exposure to the potential additional heat of direct sunlight.
The location should be free of dust and other airborne pollutants and well ventilated enough to process any fumes
produced by the engraving process in accordance with all applicable laws and regulations. Depending on the
materials to be processed, this may require construction of a dedicated ventilation system. It should be away from
children; combustible, flammable, explosive, or corrosive materials; and sensitive EMI devices. The power cord
should be plugged into a compatible and stable power source via a grounded 3-prong outlet. No other item should
be drawing current from the same fuse. There should be fire-fighting equipment nearby and the local fire station's phone
number should be clearly displayed.
It is highly recommended to have an extra work table nearby in order to avoid placing objects on or directly adjacent to
the machine, which could become a fire or laser hazard.
3.3 Electrical Grounding
This device employs a class 4 laser. As discussed in the Safety Information above, it is extremely high voltage and
potentially dangerous, so users must securely ground it to avoid the buildup of static electricity. Using a standard
3-prong outlet will provide sufficient grounding. If you do not have access to a 3-prong outlet, you MUST use the
grounding cable and ensure its proper connection. The far end of the cable should be securely connected to a metal rod
driven at least 3 m (8 feet) deep into soil located at least 1.5 m (5 feet) from the machine. The resistance along the line
should be no greater than 5Ω.
Poor grounding WILL cause equipment failure and create a serious electrical shock hazard. The
manufacturer and/or seller bear(s) no responsibility and assume(s) no liability for any damage,
accidents, or injuries caused by bad grounding connections.
