Stand-on Floor Scale
USER MANUAL
MS3400-1
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS3400-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Charder MS3400-1

  • Page 1 Stand-on Floor Scale USER MANUAL MS3400-1 Please keep the instruction manual at hand and follow instruction for use.
  • Page 2: Table Of Contents

    CONTENTS I.Explanation of Graphic Symbols on Label/Packaging ..... 3 II. Copyright Notice ..............5 III. Safety Notes ............... 6 A. General Information ............6 B. EMC GuidanceandManufacturer's Declaration ......10 IV. Installation ................ 10 A. Assembly ................ 14 B. Replacing Batteries ............17 C.
  • Page 3: I.explanation Of Graphic Symbols On Label/Packaging

    I.Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
  • Page 5: Copyright Notice

    This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.
  • Page 6: Safety Notes

    III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.
  • Page 7: Safety Instructions

    - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk...
  • Page 8: Maintenance

    Warranty/Liability If Charder is responsible for a fault or defect present upon receipt of  the unit, Charder shall either repair the fault, or supply a replacement unit.
  • Page 9: Incident Reporting

    Warning  Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction.  Do not touch the power supply with wet hands.  Do not crimp the power cable, and avoid sharp edges.
  • Page 10: Emc Guidanceandmanufacturer's Declaration

    B. EMC GuidanceandManufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guid...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromag test level netic...
  • Page 12 NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance...
  • Page 13 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheore ticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.
  • Page 14: Installation

    IV. Installation A. Assembly 1. Insert column into column seat. 2. Insert and fasten 3 M4*0.7*15 screws at the bottom of the base...
  • Page 15 3.Route the cable along the gap in the column seat. 4. Place bottom cover in position. Insert and fasten four M4*0.7*8 screws.
  • Page 16 Using wheel castor (optional) 1. If installed on device, wheel castor is located behind column 2. Press the brake down to lock the castor wheel...
  • Page 17: Replacing Batteries

    B. Replacing Batteries 1. Open battery housing cover, and remove battery holder from compartment. 2. Disconnect rechargeable battery cable from connector in the battery compartment Connector in the battery housing...
  • Page 18 3. Connect cable with connector, and insert rechargeable battery pack in battery compartment. 4. Place battery cover in place The rechargeable battery should be recharged at least once every 3 months, regardless of if the device has been used. Battery can be charged by plugging device's exclusive adapter into AC Connector Port.
  • Page 19: Using Adapter

    C. Using Adapter 1. Connect adapter to indicator before connecting to mains power supply 2. Disconnect adapter from mains power supply before unplugging adapter pin from indicator. NOTE: Connect adapter to charge rechargeable batteries. Please charge batteries for at least 14 hours before first use. AC Connector Port...
  • Page 20: Attaching Height Rod To Column

    D. Attaching Height Rod to Column Step 1. Attach two fixing blocks to Step 2. Attach height rod to blocks column using four flat-head using two flat-head screws screws Item Name Quantity Fixing block screws Fixing blocks Height Rod to fixing block screws * Photo of display for reference only.
  • Page 21: Using Hm201M Height Rod

    E. Using HM201M Height Rod Measurement over 121 cm 1. Pull out rod 2. Unfold head piece to horizontal position 3. Height reading found at point A...
  • Page 22 Measurement under 121 cm 1. Fold head piece and press buckle 2. While pressing on buckle, pull down head piece 3. Height reading found at point...
  • Page 23: Indicator

    V. Indicator A. Indicator and Key Functions Key Function 1. HOLD/BMI: Determine stable weighing value - used when weight is unstable. Press and hold for 3 seconds to enter BMI mode. 2. UNIT/WEIGHT: Switch between kg/lb. Change height value when indicator is in BMI mode.
  • Page 24: Using Device

    VI. Using Device A. Basic Operation Switch on the device using [ON/ZERO/OFF] key. The device will automatically perform self-calibration, displaying software version. Once "0.0 kg" appears on indicator, device is ready for measurement. Note: If "0.0 kg" does not display on indicator, press [ON/ZERO/OFF] key to zero the device.
  • Page 25: Bmi

    C. BMI 1. In normal mode, press and hold the [HOLD/BMI] key for at least 3 seconds to enter BMI mode. 2. Display will show last recorded height. Left-most digit will flash. 3. Press [UNIT/WEIGHT] key to change height value. Press [HOLD/BMI] key to manually move to next digit.
  • Page 26: Device Setup

    VII. Device Setup Calibration Procedure Press and hold [ON/ZERO/OFF] button. Without letting go of the [ON/ZERO/OFF] button, press [UNIT/WEIGHT] button 3 times. LCD screen will display a zero count value between 2000 and 10000. Press [UNIT/WEIGHT] to select calibration weight unit (kg/lb) Press [TARE] button.
  • Page 27: Troubleshooting

    Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit.
  • Page 28 3. Connection failure for data transmission Ensure wires are connected correctly  Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ...
  • Page 29 Error Messages Error Message Reason Action Low battery warning Replace batteries, or Voltage of battery is too plug in adapter low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try again capacity Counting Error (too Error normally caused low) by faulty loadcell or...
  • Page 30: Product Specifications

    IX. Product Specifications A. Device Information Model MS3400-1 Display DP2701 Weight Capacity 300 kg x 0.1kg Measurement Accuracy ± 0.2 kg Unit kg / lb LCD Screen 1.0-inch LCD screen Dimensions Overall 310(W) x 460(D) x 1070(H) mm Platform 310(W) x 310(D)
  • Page 31: Power Adapter Standards

    B. Power Adapter Standards Warning The device is only compatible with the power adapters specified in the dashed block below. DRAWING NO. CE APPROVED TYPE NO. / TYPE Adapter plug VOLTAGE MODEL NO. CD-AD-00044 UES12LCP-120100SPA 12V 1A CD-AD-00044 UES12LCP-120100SPA CD-AD-00044 UES12LCP-120100SPA CD-AD-00044 UES12LCP-120100SPA...
  • Page 32: Standard Parts

    C. Standard Parts Accessories Item Spec M4 Screw M4*0.7*15 M4 Screw M4*0.7*8 Bottom Cover RS232 WR-2781 cable...
  • Page 33 Notes _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...
  • Page 34 Notes _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...
  • Page 35 Notes _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...
  • Page 36: Declaration Of Conformity

    X. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
