Charder MS3500 User Manual

Infant scale
Hide thumbs Also See for MS3500:

Advertisement

Quick Links

Download this manual
Infant Scale
USER MANUAL
MS3500
Infant Scale
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charder MS3500

Summary of Contents for Charder MS3500

  • Page 1 Infant Scale USER MANUAL MS3500 Infant Scale Please keep the instruction manual at hand and follow instruction for use.

  • Page 3: Table Of Contents

    CONTENTS Explanation of Graphic Symbols on Label/Packaging ..4 I. Safety Notes ............... 7 A. General Information ...........7 B. EMC GuidanceandManufacturer's Declaration ..11 II. Installation.............. 15 A. Attaching tray ..........15 B. Height Measure Attachment ......16 C. Inserting Batteries ........... 17 D.

  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
  • Page 6 Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.

  • Page 7: Safety Notes

    I. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.

  • Page 8: Intended User Profile

    (b) Weight: no restrictions within device weight capacity (c) Patient Conditions: require measurement of body weight. Can fit upon device. Intended user profile (a) At least 20 years old (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g.
  • Page 9 Cleaning Device surface should be cleaned using alcohol-based wipes. Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device. Warranty/Liability The period of warranty shall be eighteen(18) months, ◼...

  • Page 10: Incident Reporting

    All maintenance, technicalinspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.

  • Page 11: Emc Guidanceandmanufacturer's Declaration

    B. EMC GuidanceandManufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance environment-guidance RF emissions...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic test level environment-guidance...
  • Page 13 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level environment-guidance...
  • Page 14 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheoreticall ywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.

  • Page 15: Installation

    II. Installation A. Attaching tray 1. Slide tray onto device 2. Turn device upside down. Secure tray to device by turning knob on each side of tray. (turn clockwise to tighten, turn counter-clockwise to loosen) 3. Device can now be used for measurement.

  • Page 16: Height Measure Attachment

    B. Height Measure Attachment 1. Attach bracket to device and baby tray, and fasten screws using screwdriver. Bracket 2. Connect height measure attachment to bracket. A clicking noise will be heard.

  • Page 17: Inserting Batteries

    C. Inserting Batteries 1. Locate battery cover on 2. Take battery connector bottom of device out from housing 3. Device uses 9V battery 4. Connect 9V battery to connector 5. Place battery into housing.Close cover and turn scale right-side up. Power on device to test if batteries are installed correctly.

  • Page 18: Using Ac Adapter

    D. Using AC Adapter Device can be powered viaadapterusing port located at rear of device. Plug adapter into device before plugging into mains. AC adapter port...

  • Page 19: Indicatorand Key Functions

    III. Indicatorand Key Functions Key Functions 1. UNIT:Switch between kg/lb 2. HOLD: Determine stable weighing value - used when weight is unstable 3. ON/ZERO/OFF: Turn device on and off. Zero scale (± 2% of full capacity). Press and hold for 3 seconds to turn off device Indicator 4.

  • Page 20: Using Device

    IV. Using Device A. Basic Operation Switch on the device using [ON/ZERO/OFF] key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press [ON/ZERO/OFF] key to zero the device.

  • Page 21: Hold

    C. Hold The hold function determines average weight, designed to be used if subject's weight will not stabilize (ex: an active infant). Note: if fluctuation is too severe, average weight determination will be difficult and hold may not function correctly 1.

  • Page 22: Device Setup

    V. Device Setup When the device is switched off, press and hold the [ON/ZERO/OFF] key. You will hear one beep- without letting go of the [ON/ZERO/OFF] key, press [UNIT] 3 times, and release the [ON/ZERO/OFF] key.The display will showthe software version followed by"Unit” (first option in setting menu).
  • Page 23 The gravity value for the device's location can be adjusted if you plan to move it to another country. Setting the correct gravity value for the new location is essential for maintaining accuracy. Please reach out to your local Charder scale service provider for assistance.
  • Page 24 Beep: When function is turned on, beeping noise will be made when: indicator is turned on, keys are pressed, and weight is stable. Press [UNIT] to toggle between on/off. Press [HOLD] key to confirm selection.

  • Page 25: Troubleshooting

    VI. Troubleshooting Product Defects Before contacting your local Charder distributor for repair service, we recommend considering the following troubleshooting procedures: Self-inspection 1. Device will not power on If battery power is depleted, replace with new batteries ◼ If batteries are not used, check if the power adapter is ◼...
  • Page 26 Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty ◼...

  • Page 27: Error Messages

    Error Messages Error Message Reason Action Low battery Replace batteries, warning or plug in adapter Voltage of battery is too low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try capacity again Counting Error Error normally (too high) caused by faulty...

  • Page 28: Product Specifications

    VII. Product Specifications A. Device Information Model MS3500 Capacity / 0-10 kg x 5g Graduation 10-20kg x 10g Accuracy ± 2e Weight Measurement 1.0-inch LCD screen LCD Screen (5 digits) Unit kg/lb 560(W) x 342(D) x 105(H) Total 560(W) x 290(D) x 65(H)

  • Page 29: Power Adapter Standards

    B. Power Adapter Standards . Warning The device is only compatible with themanufacturer's power adapters CE APPROVED TYPE Adapter DRAWING NO.: TYPE VOLTAGE NO. / MODEL NO.: plug UES06WOCP- 12V 0.5A CD-AD-00028 120050SPA UES06WOCP- 12V 0.5A CD-AD-00028 120050SPA UES06WOCP- 12V 0.5A CD-AD-00028 120050SPA UES06WOCP-...
  • Page 30 Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
  • Page 31 Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...

  • Page 32: Declaration Of Conformity

    VIII. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
