  • Page 1 Single Ultrawide Monitor Extra Tall Desk Mount SKU: STAND-V100R Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-v100r...
  • Page 2 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
  • Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 4: Package Contents

    Package Contents C (x1) A (x1) B (x1) Lower Pole VESA Bracket Clamp D (x1) E (x1) F (x1) Upper Pole Support Plate Pole Cap G (x2) H (x1) I (x5) Cable Clip Grommet Plate Included Hardware & Tools M-A (x4) M-B (x4) M-C (x4) M4x12mm...
  • Page 5: Assembly Steps

    ASSEMBLY STEPS STEP 1a Assembly Option #1 - Desk Clamp Install Lower Pole (C) to Clamp (B) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Remove protective film from Pads (I) and apply them to Clamp (B) as shown. Secure clamp assembly to desktop by tightening hand bolt.
  • Page 6 STEP 1b Assembly Option #2 - Grommet Remove Screw (B1) from Clamp Bolt (B2) and remove Clamp Bolt (B2) from Clamp (B). Remove protective film from Pads (I) and apply them to the bottom side of Grommet Plate (H).
  • Page 7 Grommet - Cont’d Align the Pin on top of Grommet Plate (H) with the Small Hole on the bottom of Lower Pole (C) and position the parts over the grommet hole. Attach to the desktop using Support Plate (E) and Clamp Bolt (B2). Small Hole My Desk Does Not Have a Grommet...
  • Page 8 STEP 2 Place Screw Cap (F) into Upper Pole (D), then twist Upper Pole into Lower Pole (C). Slide both Pole Cable Clips (G) over Pole assembly, then slide VESA Bracket (A) onto the Upper Pole. Adjust the height location of the VESA Bracket and tighten using the 6mm Allen Wrench (T-B).
  • Page 9 STEP 3 Loosen the Thumbscrew (A2) on the back of both VESA Brackets (A1), then separate and remove VESA Plates (A3) by pulling out and sliding upwards. Install the VESA Plates (A3) onto the back of your monitors using M4x12mm Screws (M-A) or M5x12mm Screws (M-B) and M5 Washers (M-C), orienting the arrow on the VESA Plates pointing up.
  • Page 10 STEP 4 Adjusting the Tilt Joint Adjustment Screw Loosen Tilt Joint: Set Angle Use 6mm Allen Wrench (T-B) to Firmly grip the VESA Bracket and loosen the Tilt Joint Adjustment adjust to your desired viewing Screw, located on the side of angle, and hold in place.
  • Page 11 STEP 5 With the assistance of a second person, line up the VESA Plates (A3) on your monitors with the VESA Bracket (A1) and the Plate Hooks into the pockets of the VESA Brackets. Monitor & VESA Brackets may need to be angled backwards slightly when sliding on. 2 Person Mounting is Recommended *Monitor &...
  • Page 12 Fine Tune Tilt Angle If the monitor is angled further than intended... Heavy Weighted/ Ultrawide Monitors [ 22lbs - 44lbs ] Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the...
  • Page 13 STEP 6 Make adjustments as desired on swivel and orientation. *If you are using the stand with the clamp, do NOT extend the arm past the back of the clamp to prevent possible damage to your monitor and stand.
  • Page 14 STEP 7 Route cables through Pole Cable Clip (G) and store Allen Wrenches provided slots.
  • Page 15 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
  • Page 16: Last Updated

    LAST UPDATED: 03/29/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
