Pneumatic Arm Single Ultrawide Monitor
Desk Mount
Instruction Manual
SKU: STAND-V100D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v100d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V100D
Summary of Contents for Vivo STAND-V100D
- Page 1 Pneumatic Arm Single Ultrawide Monitor Desk Mount Instruction Manual SKU: STAND-V100D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v100d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Cut the shipping tie from Arm (A) while firmly holding the two halves close together. Slowly release the pressure and allow it to gradually open up to reach full extension. STEP 2: Option A - Desk Clamp Assemble Upper Clamp (B) to the underside of Arm (A) using M6x12mm Screws (S-C) and 4mm Allen Wrench (T-A). - Page 4 STEP 2: Option A - Desk Clamp - Continued Secure screws on Lower Clamp (C) using 4mm Allen Wrench (T-A). Tighten lower bolts on Lower Clamp (C) to secure to desktop using 6 mm Allen Wrench (T-B). Proceed to Step 3 at the bottom of Page 5 STEP 2: Option B - Grommet Assemble Grommet Plate (G) to under side of Arm (A) using M6x12mm Screws (S-C) and 4mm Allen Wrench (T-A).
- Page 5 STEP 2: Option B - Grommet - Continued If you are using an existing grommet hole, ensure that it is at least 10mm (3/8”) in diameter and no more than 60mm (2 3/8”). Desktop should be between 10mm-48mm (3/8” to 1 7/8”) . For desktops without an existing gromment hole, use a 3/8”...
- Page 6 STEP 4 Connect Front VESA Plate (D2) to back of Monitor using appropriate Screws (M-A, M-B), M5 Washers (M-C), and a Phillips Screwdriver. STEP 5 To mount the monitor, begin by lining up the tabs on Front VESA Plate (D2) with the slots on Back VESA Plate (D3).
- Page 7 STEP 7 Remove Cable Cover (A1) from Arm (A) by sliding it forward. Route cables and replace Cover (A1). Place Clamp Cable Clip (E) onto backside of assembly for additional cable management. 4mm and 6mm Allen Wrenches (T-A, T-B) can be stored in slots for future adjustments. STEP 8 To keep mount stable, do not extend arm fully behind desktop edge.
