Mechanical Arm Single Monitor Desk Mount
Instruction Manual
SKU: STAND-V100S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v100s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V100S and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V100S

  • Page 1 Mechanical Arm Single Monitor Desk Mount Instruction Manual SKU: STAND-V100S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v100s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Tools Needed

    TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 4.4-15.4lbs Failure to do so may result in serious injury. (2-7kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Desk Clamp Installation Assemble base (B) to clamp (C) using M6x8 bolts (E), and tighten with 5mm Allen wrench (G). Un- screw the large clamp bolt to the “open”...
  • Page 4 STEP 2 While holding arm (A) in the closed position, cut the shipping tie. 1. Firmly hold the two halves of the spring arm together and have another person cut off the cable tie from around the spring arm. 2. Slowly release the pressure on the spring arm and allow it to gradually stretch to its full extension. STEP 3 Place the arm (A) onto the base (B).
  • Page 5 STEP 5 Align bolts installed to monitor with VESA plate. Secure using two more bolts (M-A or M-B) and washers (M-C) in the bottom two holes. Tighten all four bolts with a Phillips screwdriver. STEP 6 If the arm (A) is not able to maintain a lowered po- sition, tighten bolts on the side of the arm using the 5mm Allen wrench (G).
  • Page 6 STEP 7 Tighten or loosen the tilt joint using the 5mm Allen wrench (G). Adjust the monitor position as desired.
  • Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
