Single Ultrawide Monitor Desk Mount
Instruction Manual
SKU: STAND-V100F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v100f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V100F
Summary of Contents for Vivo STAND-V100F
- Page 1 Single Ultrawide Monitor Desk Mount Instruction Manual SKU: STAND-V100F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v100f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. - Page 3 STEP 2 Install Pole (D) to Base (C) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Remove protective film from Pads (G) and apply them to Base (C) as shown. STEP 3 Slide Cable Clip (F) and VESA Bracket (B) onto Pole (D). Adjust the height location of VESA Bracket (B) and tighten using the 6mm Allen Wrench (T-B).
- Page 4 STEP 4 Mount VESA Plate (A) to monitor using appropriate Screws (M-A thru M-D), M5 Washers (M-E), and Spacers (M-F).
- Page 5 STEP 5 Slide monitor with VESA Plate onto VESA Brackets (B) and secure using M6x10mm Thumbscrew (S-B). STEP 6 Use Cable Clip (F) to route cables. Store Allen Wrenches (T-A, T-B) in slots of Clip.
- Page 6 ADJUST AS DESIRED Use 6mm Allen Wrench (T-B) to loosen or tighten Monitor Bracket (B) tension.
- Page 7 WARNING Keep the displays positioned over the desktop within the arrow range shown.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
