Single Monitor Desk Mount
Instruction Manual
SKU: STAND-V100B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v100b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V100B
Summary of Contents for Vivo STAND-V100B
- Page 1 Single Monitor Desk Mount Instruction Manual SKU: STAND-V100B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v100b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6lbs Failure to do so may result in serious injury. (8 kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach the pole cap (G) to the top of the pole (B). STEP 2 Attach the pole (B) to the clamp (C) using M6x16 bolts (H) and tighten using the 4mm Allen wrench (J). - Page 4 STEP 3 Slide the pole cable clip (E) and arm (A) onto the pole (B) and tighten using the 6mm Allen wrench (K). Attach the arm cable clips (F) to the arm (A). STEP 4 OPTION A: Flat Back Monitor Attach the VESA plate (D) to the monitor using bolts (M-A or M-C) and washers (M-E).
- Page 5 STEP 4 (Continued) OPTION B: Curved Back Monitor Attach the VESA plate (D) to the monitor using bolts (M-B or M-D), washers (M-E) and spacers (M-F). Tighten with a Phillips screwdriver. STEP 5 Slide the VESA plate (D) onto the arm (A) and secure using the thumbscrew (I).
- Page 6 STEP 6 Tighten or loosen the tilt joint using the 6mm Allen wrench (K). STEP 7 Route cables through the cable management clips (E,F).
- Page 7 STEP 8 Store tools in the cable clip. Adjust as Desired...
- Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
