Pneumatic Arm Single Ultra Wide Monitor
Desk Mount
Instruction Manual
SKU: STAND-V100H/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v100h
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V100H/W
Summary of Contents for Vivo STAND-V100H/W
- Page 1 Pneumatic Arm Single Ultra Wide Monitor Desk Mount Instruction Manual SKU: STAND-V100H/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v100h GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
PACKAGE CONTENTS A (x1) B (x1) C (x1) D (x1) E (x1) Base Rear Cover Clamp Brace Grommet Base Plate F (x1) G (x1) H (x1) I (x1) J (x2) Clamp Plate Clamp Bracket 200x100 VESA Plate Support Plate VESA Plate S-A (x2) S-B (x2) S-C (x2) -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 - Option A - Clamp Mount Attach Clamp Brace (D) to Base (A) using M6x12mm Screws (S-F), and tighten with 4mm Allen Wrench (T-B). Insert M10x63mm Clamp Bolts (S-A) into Clamp Bracket (G) as shown, then place Clamp Plate (F) on top of assembled clamp. - Page 5 STEP 1 - Option B - Grommet Place M8x105mm Carriage Bolt (S-B) into square holes in Grommet Base Plate (E). Attach Grommet Base Plate to Base (A) using M6x12mm Screws (S-F), and tighten with 4mm Allen Wrench (T-B) Place assembled base over cable grommet hole in desktop, and tighten using Support Plate (J), M8 Washers (S-C) and M8 Nuts (S-D), and tighten with Wrench (T-A).
- Page 6 STEP 2 Insert the Arm (B) into the socket of the Base (A), then secure using the 4mm Allen Wrench (T-B) or a flatblade screwdriver. Install Rear Cover (C) to Clamp Brace (D) if the clamp option was used. Install Arm Washer (S-J) to the top of Arm (B).
- Page 7 STEP 3 Connect VESA Plate (I) to Arm (B) using Spacer (S-G), M8x25mm Screw (S-I), and 6mm Allen Wrench (T-C). Ensure that hexagon side of Spacer is facing upward towards VESA Plate (I). Remove Thumbscrew (I1) from back of VESA Plate (I). Separate Front VESA Plate (I2) from Back VESA Plate (I3).
- Page 8 STEP 4 OPTION A: VESA 75x75, 100x100 Install the VESA Plate (I) to monitor using M4x12mm Screws (M-A) or M5x12mm Screws (M-B) with M5 Washers (M-C), making sure the rounded edges of the rear bracket are facing up. OPTION B: VESA 200x100 Install the 200x100 VESA Plate (H) to the VESA Plate (I) using the M4x8mm Screws (S-E) and M4 Nuts (S-H), tightening with Wrench (T-A) and a Phillips screwdriver.
- Page 9 STEP 5 To mount the monitor, begin by lining up the tabs on Front VESA Plate (I2) with the slots on Back VESA Plate (I3). Insert tabs into slots and re-install Thumbscrew (G1) into Back VESA Plate (G3) to secure. STEP 6 While holding the arm in the horizontal position, adjust the gas spring tension using the 6mm Allen Wrench (T-C).
- Page 10 STEP 7 Remove cable covers from base and adjustable arm. Organize cables and reinstall cable covers to base and adjustable arm.
- Page 11 Adjust as Desired To adjust tilt tension, use 6mm Allen Wrench (T-C).
- Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
