Projecta INTELLI-RV Instruction Manual page 21

PMTPMS
TYRE PRESSURE MONITORING SYSTEM MODULE
The Tyre Pressure Monitoring System (TPMS) monitors the RV's tyre
pressure before and during the journey.
PMLVL
LEVELLING SENSOR
Level the RV with the levelling sensor which
can be monitored via the phone app.
Calibration
To calibrate the level sensor, the RV needs to be level in both forward and back and side to side.
Once level, go to the Setting Page, select Level Sensor and press Calibrate. This will zero the sensor.
LB200-HD
12V HIGH DISCHARGE 200AH LITHIUM BATTERY
LB200-HD boast impressive capabilities
and are ideal for 4WDs and caravans with
high power demands
LB400-HD
12V HIGH DISCHARGE 400AH LITHIUM BATTERY
The LB400-HD boasts an astonishing
400Ah capacity and a market leading
300A discharge capability making it ideal
to partner with high current drawing
appliances such as 3000W inverters.
PART No. PMTPMS x 4 (one for
PART No. Reciever - PMTPMS-R
Input
Working Current
Working Temperature
Humidity
Recieving Frequency
Wired Communication
Weight
PART No. Sender - 4 x PMTPMS-S
Working Voltage
Battery Type
Transmitted Current
Transmitted Power
Transmitted Frequency
Pressure Range
Accuracy
Working Temperature
Weight
PART No.
Working Voltage
Working Current
Working Temperature
IP Rating
Accuracy
PART No.
Nominal Voltage
Nominal Capacity
Nomincal Energy
Charge Voltage
Discharge Cut-Off Voltage
Standard Charge Current
Maximum Charge Current
Maximum Discharge Current
Peak Discharge Current
Operating Temperature
Maximum Number of Batteries
In Parallel
Number Of Discharge Cycles
Weight
IP Rating
PART No.
Nominal Voltage
Nominal Capacity
Nomincal Energy
Charge Voltage
Discharge Cut-Off Voltage
Standard Charge Current
Maximum Charge Current
Maximum Discharge Current
Peak Discharge Current
Operating Temperature
Maximum Number of Batteries
In Parallell
Number Of Discharge Cycles
Weight
IP Rating
each type)
6-24V
30mA
-40°C - 85°C
<9S%
433.910Mhz
RS48S
1S0g
2.2 - 3.6V
CR1632
<5mA
<5dbm
433.910Mhz
14 - 130PSI
±1.45 PSI
-30°C - 70°C
13.8g
PMLVL
9 - 16V
30mA
-40°C - 85°C
IP20
± 2°
LB200-HD
12.8V
200ah
2560Wh
14.2V
11.2V
100 Amps
200 Amps
200 Amps
300 Amps (10mins)
-20°C - 60°C
4
3000
22Kg
IP20
LB400-HD
12.8V
400ah
2560Wh
14.2V
11.2V
100 Amps
200 Amps
200 Amps
300 Amps (10mins)
-20°C - 60°C
4
3000
22Kg
IP20
21
