INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
These instructions are supplementary to the
Installation and Operating Instructions supplied with
the fireplace and should be kept together. Refer
to the Installation and Operating Instructions for
proper gas supply, safety requirements and operat-
ing instructions.
Visit www.townandcountryfireplaces.net for the most recent version of this manual
270223-12
TCWS38
BLACK DIAMOND
BURNER KIT
INSTALLATION
INSTRUCTIONS
SKU# 22150032
For TCWS38 Series D
Fireplaces
SKU# 22150032
100005919
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces 22150032
Summary of Contents for Town & Country Fireplaces 22150032
- Page 1 Installation and Operating Instructions for proper gas supply, safety requirements and operat- ing instructions. TCWS38 BLACK DIAMOND BURNER KIT INSTALLATION INSTRUCTIONS SKU# 22150032 For TCWS38 Series D Fireplaces Visit www.townandcountryfireplaces.net for the most recent version of this manual 270223-12 SKU# 22150032 100005919...
-
Page 2: Contents Of Package
Contents of Package 2 Burner assemblies 1 Burner tray 1 Bag glass media Instructions and hardware pack 100005919 SKU# 22150032_270223-12... - Page 3 Black Diamond Burner Installation If converting to propane see conversion instructions on page 5 before proceeding. Install panels according to the TCWS.38D Installation and Operating manual prior to burner installation. Figure 1: Burner installation. Figure 2: Burner tray installation. 1. Install the right burner by tipping into location trough and slipping the venturi tube over the orifice. Repeat with left burner (Figure 1).
- Page 4 Figure 6: Installing front porcelain trim. Figure 5: Applying glass media. 5. Place glass media into the burner tray and brush smooth so that a very light layer covers the burners (Figure 5) NOTE: Too much glass media will cause sooting and improper flame pattern. 6.
-
Page 5: Propane Conversion
Propane Conversion If the unit is to be used with propane convert as follows using the components supplied with this burner. Caution: Factory supplied components must be used to ensure correct input. After conversion confirm proper manifold pressure. CAUTION: The gas supply and electrical power shall be shut off before proceeding with the conversion. WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufac- turer's instructions and all applicable codes and requirements of the authority having jurisdiction. - Page 6 Figure 12: Loosening the pilot Figure 13: Band in natural gas Figure 11: Adjusting air shutter for head. position. propane gas. 5. Loosen the primary air shutter screw, open shutter to give a gap of 1/8” (0.125”) and re-tighten. Repeat on other burner (Figure 11).
-
Page 7: Gas Pressure Check
Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. 1. -
Page 8: Burner Flame Adjustment
Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel (1/8” open for propane gas). Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. -
Page 9: Parts Diagram
Parts Diagram (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION ............PART NO. BLACK DIAMOND BURNER ........22150032 GLASS MEDIA ............TCRP.501201 PROPANE CONVERSION KIT ........22180006 NOT SHOWN 100005919 SKU# 22150032_270223-12... - Page 10 100005919 SKU# 22150032_270223-12...
- Page 11 100005919 SKU# 22150032_270223-12...
- Page 12 © 2019 Copyright Pacific Energy Fireplace Product LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
