INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
Visit www. townandcountryfireplaces.com for the most recent version of this manual
270223-16
TCWS38
REFLECTIONS
BURNER KIT
INSTALLATION
INSTRUCTIONS
SKU# 22150033
For TCWS38 Series D
Fireplaces
SKU# 22150033
100005920
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces 22150033
Summary of Contents for Town & Country Fireplaces 22150033
- Page 1 Operating Instructions for proper gas supply, safety requirements and operating instructions. TCWS38 REFLECTIONS BURNER KIT INSTALLATION INSTRUCTIONS SKU# 22150033 For TCWS38 Series D Fireplaces Visit www. townandcountryfireplaces.com for the most recent version of this manual 270223-16 SKU# 22150033 100005920...
-
Page 2: Contents Of Package
Contents of Package 5.0 lbs Glass Media Hardware Pack Burner assemblies Burner tray assembly Rock sets 100005920 SKU# 22150033_ 270223-16... - Page 3 Reflections Burner Installation If converting to propane see conversion instructions on page 8 before proceeding. Install panels according to the TCWS.38D Installation and operating manual prior to burner installation (Page 31). 1. Install the right burner by tipping into location (Figure 1) and slipping the venturi tube over the orifice.
- Page 4 Figure 4: Securing burner tray with six screws. Figure 5: Burner tray before glass media is applied. Figure 6: Applying glass media to tray. Tabs Figure 7: Clearing center of tray of glass media. Figure 8: Tabs for rock placement. 100005920 SKU# 22150033_ 270223-16...
- Page 5 NOTE: A light will aid aligning the holes in the tray with the leg. 5. Place glass media into the burner tray and spread evenly around but not on the burners or on top of the Pilot assembly (Figure 6 and Figure 7). Figure 9: Markings on bottom of Figure 10: Rock ‘A’.
- Page 6 9. Place the remaining (A) rock on the left hand end of burner as shown in Figure 20. Figure 15: Rock ‘F’. Figure 16: Rock ‘G’. 10. Install front porcelain cover (wide edge t owards the center of the fireplace) (Figure 21). 11.
- Page 7 Extra “A” Rock 3rd “A” Rock 2nd “A” Rock 1st “A” Rock Figure 22: TCWS38 Reflections rock layout. 100005920 SKU# 22150033_ 270223-16...
-
Page 8: Propane Conversion
Propane Conversion If this unit is to be used on propane convert as follows using the components supplied with this burner: Note: Factory supplied components must be used to ensure correct input. After conversion confirm proper manifold pressure. CAUTION The gas supply and electrical power shall be shut off before proceeding with the conversion. WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. - Page 9 1/8” Gap MAIN BURNER ORIFICES (LF - Paci c Energy) Figure 26: Gap in air shutter for propane. Figure 25: Propane orifice. 6. Loosen the primary air shutter screw, open shutter to give a gap of 1/8” (0.125”) and re-tighten (Figure 26).
- Page 10 This appliance was converted to propane gas Kit Number 5052.52001-B Company Address The above accepts the responsibility that this conversion has been properly performed. Figure 30: Gas valve cover. Figure 31: Propane conversion label. 9. Remove access panel (Figure 30) to gain access to the gas valve for propane conversion. 10.
-
Page 11: Gas Pressure Check
Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pres- sure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. Figure 32: Removing pressure test plug. -
Page 12: Burner Flame Adjustment
Burner Flame Adjustment The air shutter on the venturi tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For LP See “Propane Conversion” on page 8. Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. -
Page 13: Replacement Parts
Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. REFLECTIONS BURNER KIT ............22150033 PEBBLE ASSEMBLY ..............5096.921 (3) GLASS MEDIA .................TCRP.501207 TRIM ROCK (for random placement) ..........5096.922 PROPANE CONVERSION KIT ............22180006 NOT SHOWN... - Page 14 100005920 SKU# 22150033_ 270223-16...
- Page 15 100005920 SKU# 22150033_ 270223-16...
- Page 16 © 2019 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
