TCWS54
SEE THRU
DIAMOND BURNER
INSTALLATION KIT
INSTRUCTIONS
SKU# 22150052
For TCWS54ST and
TCWS54ST Indoor/Outdoor
Series D Fireplaces
SKU# 22150052
100005917
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces 22150052
Summary of Contents for Town & Country Fireplaces 22150052
- Page 1 Operating Instructions for proper gas supply, safety requirements and operating instructions. TCWS54 SEE THRU DIAMOND BURNER INSTALLATION KIT INSTRUCTIONS SKU# 22150052 For TCWS54ST and TCWS54ST Indoor/Outdoor Series D Fireplaces Visit www.townandcountry.com for the most recent version of this manual 060323-28 SKU# 22150052...
-
Page 2: Table Of Contents
Table of Contents Contents of Package ..............3 Diamond Burner Installation ............4 Propane Conversion ..............13 Orifice conversion procedure ........... 13 Accessing the gas valve for conversion ......16 Gas Pressure Check ..............19 Correct gas pressure requirement:........19 Burner Flame Adjustment ............ -
Page 3: Contents Of Package
Contents of Package Secondary oor panels Glass media tray Burners INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. These instructions are supplementary to the Installation and Operating Instructions supplied with the replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. -
Page 4: Diamond Burner Installation
Diamond Burner Installation If converting to propane see “Propane Conversion” on page 13 before proceeding. NOTE: For purposes of clarity, the “Front” of the fireplace shall be the side which has access to the electrical connection compartment cover, the connection to the gas valve and the side which places the control compartment cover and the coaxial vent located on top of the fireplace to your left. - Page 5 Grommet Figure 3: Wires through grommet. 2. Feed the two wires from the right side secondary floor panel down through the left most grommet over the gas control compartment cover (Figure 3). 3. Insert the other secondary floor panel into the left side of the firebox. As the panel is lowered, feed its two lights wires into the same grommet as was done with the wires from the right hand floor panel.
- Page 6 Figure 5: Lights wiring coming from grommet. 4. Guide the four light wires from the bottom of the gas control compartment out through the opening as shown in Figure 5. 5. From inside the control compartment, punch out one of two available knockouts located in the electrical connection compartment, install a plastic grommet (not included) to protect the wires and feed the wires into the compartment.
- Page 7 Figure 7: Bringing wires through front plate. 6. Remove the electrical connection compartment cover and feed all four lights wires through the opening. The lights wiring will connect to the wiring that supplies the fire place power (Figure 7). 7. Connect the wires to a switched 120 VAC, 60Hz, 3A power supply, one pair made up of one wire from the left and one wire from the right light set to the “HOT”...
- Page 8 Figure 9: Securing the burner leg to the secondary floor panel. 10. Slip the gas burner venturi over the orifice and screw the burner leg to the secondary floor panel using a T20 screw (Figure 9). 11. Place the second burner in the firebox so that its venturi fits over the second orifice. Secure the leg to the secondary floor panel.
- Page 9 12. Remove the panel retainer clips from both sides of the upper firebox in preparation for side panel installa- tion (Figure 11). There are two clips on each side of the firebox. Side panel retainer clips Figure 11: Side panel retainer clips location. Figure 12: Side panel.
- Page 10 Reinstalled Side panel retainer clips Figure 14: Reinstalled side panel retainer clips. 14. Reinstall the side panel retainer clips (Figure 14) . 15. Place glass media tray over top of the burners so that its legs rest on the secondary floor. The side of the tray with the mesh strip crossing over from one side to the other must be positioned over top of the pilot assembly.
- Page 11 Screws Screws Figure 16: Glass media tray installation. 16. Secure the glass media tray to the burners with screws provided by screwing through the mesh to each small flange on the burners. There are 10 securing points for each burner (Figure 16). 17.
- Page 12 Narrow edge toward center of replace Figure 19: Porcelain edge panel profile. Figure 20: Raised dome to accommodate pilot flame. 18. Spread the three bags of glass media evenly over the entire mesh tray, leaving only the small raised dome protruding above the pilot flame clear of glass (Figure 20).
-
Page 13: Propane Conversion
Propane Conversion If this unit is to be used on propane convert as follows using the components supplied with the propane gas conversion kit. Propane conversion kit part number is SKU# 22180011. Note: Factory supplied components must be used to ensure correct input. After conversion confirm proper manifold pressure. - Page 14 3/16” Open for Propane Gas Figure 22: Orifice. 4. Using a 1/2” wrench, undo the natural gas burner orifices and Figure 23: Shutter gap for propane. replace with the propane gas orifices included in the conver- sion kit. Apply a small amount of pipe joint compound to the threads of the propane burner orifice to ensure a good seal,...
- Page 15 7. Slide the pilot adjustment band over (Figure 26) and ensure that the hole in the orifice band is showing. 8. Remove access panel to gain access to the gas valve for propane conversion. 9. Complete the gas valve con- version from natural gas to propane gas according to the instructions included in the...
-
Page 16: Accessing The Gas Valve For Conversion
Accessing the gas valve for conversion Grommet Figure 28: Wires through grommet. 1. If installed, remove the burner media (rocks, glass, etc.) from the burner tray. Remove the edge panels, burner tray, left hand burner, left hand side panel, release pilot assembly from center leg and remove left hand secondary floor panel. - Page 17 Figure 30: Small plate lifted to proved access to connector. 3. Remove screws for the small cover panel and lift the panel and flexible gas lines enough to be able to get your hand underneath it (Figure 30). 4. Locate the stepper (Figure 31) and follow its wires back to its electrical connection and discon- nect (Figure 32).
- Page 18 Figure 32: Stepper connector location. included in the SIT propane gas conversion kit. 7. Once conversion is complete, fill out and affix the gas conversion label (Figure 33) to the inside of the gas valve inside of control box where it will not be affected by the heat of the firebox. This appliance was converted to propane gas Kit Number 5052.52001-B...
-
Page 19: Gas Pressure Check
Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. 1. -
Page 20: Burner Flame Adjustment
Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For liquid propane, See “Propane Conversion” on page 13. Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. -
Page 21: Optional Long Beach Log Set Installation
Optional Long Beach Log Set Installation Log 1 x 2 pieces Log 2 x 2 pieces Log 4 x 2 pieces Log 3 x 2 pieces Figure 37: Contents of Long Beach log set. Log Placement The Long Beach Log Set consists of four pair of logs for a total of eight logs. Four of the logs will cover one half of the circumference of the glass tray while the other four will duplicate the pattern of the of the first four. - Page 22 Edge Panel Location post for 3rd log Edge Panel Figure 39: Log 2 placement. 2. Place the 2nd log so that the middle of it overhangs the tray itself and rests on the edge panel as shown in Figure 39. Note that there is a location post for the 3rd log at one end of the 2nd log. This location post should have a vertical alignment.
- Page 23 Edge Panel Edge Panel Figure 41: Log 4 placement. 4. The 4th log also has a socket which will fit over top of the location post of the 3rd log. Fit the 4th log over the location post and let the opposite end rest on the glass at about a 1 o’clock position (Figure 41). 5.
- Page 24 Figure 43: Example of desirable flame pattern. 100005917 SKU# 22150052_060323-28...
-
Page 25: Lights Wiring Diagram
Lights Wiring Diagram Figure 44: TCWS54ST lights wiring diagram. 100005917 SKU# 22150015_060323-28... -
Page 26: Replacement Parts
Parts Diagram (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION .....................PART NO. DIAMOND BURNER KIT ..................22150052 GLASS MEDIA (1-5lb bag. 2 required) ..............12160016 LONG BEACH LOG SET (For use with Diamond Burner Kit only ......22160008 NOT SHOWN... - Page 27 100005917 SKU# 22150015_060323-28...
- Page 28 © 2017 Copyright Pacific Energy Fireplace Product LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please call your retailer. Web site: www.townandcountryfireplaces.com 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
