INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
270223-12
TCWS54
TRANQUILITY
BURNER KIT
INSTRUCTIONS
SKU# 22150051
For TCWS54 Series D
Fireplaces
SKU# 22150051
100005921
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces 22150051
Summary of Contents for Town & Country Fireplaces 22150051
- Page 1 Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TCWS54 TRANQUILITY BURNER KIT INSTRUCTIONS SKU# 22150051 For TCWS54 Series D Fireplaces 270223-12 SKU# 22150051 100005921...
-
Page 2: Contents Of Package
Contents of Package Figure 1: TCWS54 Black Diamond Burner parts. 3.4 LBS SAND HARDWARE PACK EQUALIZER ROCKS BURNER ASSEMBLIES BURNER TRAY ASSEMBLY PEBBLE SETS SKU# 22150051_270223-12... - Page 3 Tranquility Burner Installation If converting to propane see conversion instructions on page #7 before proceeding. Install panels according to the TCWS.54CE Installation and Operating manual prior to burner installation. (Page 23) Install the right burner by tipping into location trough and slipping the venturi tube over the orifice. Test for connection by lifting at a location pin on the right side of the burner.
- Page 4 Figure 6: TCWS54 Black Diamond Burner parts. Figure 7: TCWS54 Black Diamond Burner parts. NOTE: check air shutter for correct fuel setting before proceeding further. Both burners are the same. Fully closed for natural gas. Secure the burner tray to legs using eight screws (Fig. #6) 13/64 (0.2)”...
- Page 5 Each rock has a slot in it’s base and is marked with a letter and an arrow. (Fig. #8) Figure 8: Rock markings Figure 12: Rock D Place each rock as per the following photographs, start from the right hand side of the burner and ensure that the arrow on each rock points towards the front of the fireplace.
- Page 6 Place the two remaining rocks on the left hand end of burner as shown. (Fig. #18 and 19) Figure 16: Rock H Figure 18: Rock A Figure 19: Rock B Figure 17: Rock J Repeat the sequence of placing the rocks three more times until the burner is covered.
-
Page 7: Propane Conversion
Propane Conversion If the unit is to be used on propane convert as follows using the components supplied with this burner: CAUTION The gas supply and electrical power shall be shut off before proceeding with the conversion. Note: Factory supplied components must be used to ensure correct input. After conversion confirm proper manifold pressure. If installed remove the rocks from the burners. - Page 8 Figure 23: Adjust shutter. Figure 24: Adjust shutter. Figure 25: NG Position. Figure 26: LP Position. Loosen the primary air shutter screw, open shutter to give a gap of 13/64” (0.2”) and re-tighten. Repeat on other burner. (Fig. #23) With a 7/16” wrench loosen the pilot head on the pilot assembly. (Fig. #24) 6.
-
Page 9: Gas Pressure Check
Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. SUPPLY PRESSURE MANIFOLD... -
Page 10: Burner Flame Adjustment
Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For LP see Pg.8. Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. Evaluate flame appearance after the fireplace has reached operating temperature. -
Page 11: Parts Diagram
Parts Diagram (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ................PART NO. #1..TRANQUILITY BURNER KIT ........22150051 #2..PEBBLE ASSEMBLY........... 5096.921 #3..SAND ..............TC42.SAND34 (Two Bags Per Kit) #4..TRIM ROCK “A” 5096.922 #5..TRIM ROCK “B” ............5096.923 NOT SHOWN... - Page 12 © 2022 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please call your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
