INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the
Installation and Operating Instructions supplied
with the fireplace and should be kept together.
Refer to the Installation and Operating Instructions
for proper gas supply, safety requirements and
operating instructions
170223-16
TC36D
COUNTRY HOME
BURNER KIT
INSTRUCTIONS
(NATURAL GAS ONLY)
SKU# 22150017
For TC36D & TC36D Arch
Series D
SKU# 22150017
100005912

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 22150017 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces 22150017

Summary of Contents for Town & Country Fireplaces 22150017

  • Page 1 Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions TC36D COUNTRY HOME BURNER KIT INSTRUCTIONS (NATURAL GAS ONLY) SKU# 22150017 For TC36D & TC36D Arch Series D 170223-16 SKU# 22150017 100005912...

  • Page 2: Contents Of Package

    Figure 1: TC36 and TC36 Arch Country Home burner kit contents. Burner/ Grate Installation Screws Figure 2: Firebox base. 1. Place the keyhole slots of the burner (Figure 3) over the two screws located on the firebox floor (Figure 2). 100005912 SKU# 22150017 170223-16...
  • Page 3 2. Slide the burner back to engage the screws in the small part of the keyhole slot and tighten screws (Figure 4). 3. Remove access cover to the valve control center from right side of firebox (Figure 5) Figure 5: Access cover to valve control center. 100005912 SKU# 22150017 170223-16...
  • Page 4 Bulkhead plate Figure 7: Ignition and sensor wire routing. 5. Feed the ignition and sensor wires through the bulkhead plate to the interface module. Tuck the ignition and sensor wires below the supply tubes (Figure 7). 100005912 SKU# 22150017 170223-16...
  • Page 5 7. Reinstall the valve control center access panel (See Figure 5 on page 3). A panel set must now be installed before the before the log grate can be installed. See Installation and Operating Instructions manual for details. 100005912 SKU# 22150017 170223-16...
  • Page 6 8. Position the slots of the grate securing brackets over the holes in the floor shield and secure with the two screws (Fig. # 9). 9. Attach rear deflector to rear of grate using the two screws provided (Figure 10). AIR DEFLECTOR SECURING SCREWS Figure 10: Rear air deflector. 100005912 SKU# 22150017 170223-16...

  • Page 7: Ember Material Placement

    Place remaining ember material outside of the burner pan as desired to cover-up gas lines and brackets. Note: Ember material placement and amount will affect flame appearance. More ember material results in lower flame height. Add or remove as needed until desired flame affect. 100005912 SKU# 22150017 170223-16...

  • Page 8: Log Placement

    Note: Improper placement of logs will cause sooting on internal parts and glass. The logs may need to be repositioned slightly to avoid excessive flame impingement. Figure 12: First log placement. Figure 13: 2nd log placement. 100005912 SKU# 22150017 170223-16...
  • Page 9 Figure 14: 3rd log placement. Figure 15: 4th log placement. 100005912 SKU# 22150017 170223-16...
  • Page 10 Figure 16: 5th log placement. Figure 17: 6th log placement. 100005912 SKU# 22150017 170223-16...
  • Page 11 Figure 18: 7th log placement. Figure 19: Completed log placement. 100005912 SKU# 22150017 170223-16...

  • Page 12: Gas Pressure Check

    Correct gas pressure requirement: Supply Pressure Natural Gas (For purpose of input adjustment) SUPPLY PRESSURE Minimum 5.0" WC MANIFOLD Maximum 13.9" WC PRESSURE Manifold Pressure Maximum 3.5" WC Minimum 1.6" WC Figure 22: Testing port location 100005912 SKU# 22150017 170223-16...

  • Page 13: Burner Flame Adjustment

    3. Remove the air deflector from the log grate. 4. Loosen the screw in the Primary Air Shutter (Figure 24). 5. Rotate the shutter to increase or decrease the amount of primary air. 6. Re assemble in reverse order. 100005912 SKU# 22150017 170223-16...

  • Page 14: Replacement Parts

    (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #4..PILOT ASSEMBLY ......TCRP.5005025 #1..COUNTRY HOME BURNER ASSY ..22150017 #5..MAIN SUPPLY TUBE ......5019.223 #2..7 PCS LOG SET ......... 5098.746108 #6..PILOT TUBE ........5019.225 #3..
  • Page 15 100005912 SKU# 22150017 170223-16...
  • Page 16 © 2017 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
