DoorProtect G3 Fibra Benutzerhandbuch
DoorProtect G3 Fibra ist ein kabelgebundener Öffnungs-, Erschütterungs- und
Neigungsmelder. Es unterstützt den Anschluss eines kabelgebundenen Melders
eines Drittanbieters mit einem öffnergeschlossenen (NC) Kontakttyp. Das Gerät
ist nur für den Innenbereich bestimmt. Entspricht den Anforderungen der Klasse
3 (EN 50131).
DoorProtect G3 Fibra ist kompatibel mit
Verbindung zu anderen
uartBridge
ist nicht vorgesehen.
Der Melder tauscht Daten mit der Hub-Zentrale über das sichere
kabelgebundene Kommunikationsprotokoll Fibra aus. Die kabelgebundene
Kommunikation kann bis zu 2.000 Meter lang sein, wenn sie mit dem U/UTP
Cat.5 Twisted-Pair-Kabel verbunden wird.
DoorProtect G3 Fibra ist Teil der Fibra-Produktlinie von kabelgebundenen
Geräten. Nur akkreditierte Partner von Ajax Systems können Fibra-Produkte
Aktualisiert am 20. Oktober 2023
Hub-Hybrid (2G)
Hubs Funk-Repeater für Funksignale ocBridge Plus
,
und
Hub-Hybrid (4G)
.
,
und

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DoorProtect G3 Fibra and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX DoorProtect G3 Fibra

Summary of Contents for AJAX DoorProtect G3 Fibra

  • Page 1 DoorProtect G3 Fibra Benutzerhandbuch Aktualisiert am 20. Oktober 2023 DoorProtect G3 Fibra ist ein kabelgebundener Öffnungs-, Erschütterungs- und Neigungsmelder. Es unterstützt den Anschluss eines kabelgebundenen Melders eines Drittanbieters mit einem öffnergeschlossenen (NC) Kontakttyp. Das Gerät ist nur für den Innenbereich bestimmt. Entspricht den Anforderungen der Klasse 3 (EN 50131).
  • Page 2 5. Montageplatte des Meldergehäuses. Es wird verwendet, um das Gerät am Abstandshalter oder direkt an der Ober äche zu befestigen. 6. QR-Code mit der Geräte-ID. Es wird verwendet, um den Detektor zum Ajax- System hinzuzufügen. 7. Perforierter Teil des Meldergehäuses. Brechen Sie es nicht ab. Notwendig für die Manipulationsauslösung im Falle eines Versuchs, den Melder von der...

  • Page 3: Operating Principle

    DoorProtect G3 Fibra has two reed switches so that the magnet can be installed both on the left or right of the detector. The device works correctly with one magnet on one side only.
  • Page 4 Learn more Sending events to the monitoring station The Ajax system can transmit alarms to the PRO Desktop monitoring app as well as the central monitoring station (CMS) in the formats of SurGard (Contact...

  • Page 5: Selecting The Installation Site

    When an alarm is received, the operator of the security company monitoring station knows what happened and precisely where to send a fast response team. The addressability of Ajax devices allows sending events to the PRO Desktop or the CMS, the type of the device, its name, security group, and virtual room.

  • Page 6: Installation Recommendations

    Installation on metal surfaces Installation on non-metallic surfaces DoorProtect G3 Fibra can be installed on sliding systems and roller shutters. If the magnet slides over the detector for a long time during closing/opening, false alarms are possible. To avoid this, disable the magnetic masking detection function.
  • Page 7 door or window). What are spacers for: 1. To install the detector or the magnet on a metal surface. 2. To reduce the distance between the detector and the magnet. For example, when you need to align the magnet with the detector on a door or window. If the window has a ventilation mode, the detector should be installed on the upper part of the window.
  • Page 8 You do not need to install a magnet near the detector if you want to use only the shock and/or tilt sensor. Disable the primary detector and the magnetic masking sensor in the DoorProtect G3 Fibra settings How not to install the detector 1.

  • Page 9: Detection Zone

    Fibra signal strength Fibra signal strength is the ratio of undelivered or corrupted data packages to those expected over a speci c time. The icon in the Devices tab in Ajax apps indicates the signal strength: Three bars — excellent signal strength.

  • Page 10: Preparing For Installation

    Tips for designing the Fibra system project DoorProtect G3 Fibra can be connected at any point of the Fibra line. Wired communication can be up to 2,000 meters long when connected using the U/UTP cat.5 twisted pair cable.

  • Page 11: Cable Arrangement

    1. Turn off the power of lines in the Ajax PRO app 1. Hub → Settings → Lines → Lines Power Supply. 2. Route the cable to connect DoorProtect G3 Fibra to the hub casing. Connect the wires to the required hub line.
  • Page 12 +24V — 24 V⎓ power terminal. A, B — signal terminals. GND — ground. 3. Remove the back panel of the detector. Carefully break out the perforated part to output the cable. 4. Run the cable from the hub into the detector enclosure through the hole that was made.
  • Page 13 When using other fasteners, ensure they do not damage or deform the mounting panel. The front lid of DoorProtect G3 Fibra can be rotated 180° during installation. You can conveniently run the wires from the top or bottom. If the wires are routed from the bottom of the detector, the magnet must be mounted in such a way that the screw is also positioned from the bottom.

  • Page 14: Adding To The System

    Connect a wired roller shutter motion detector with a normally closed (NC) contact type to DoorProtect G3 Fibra to receive an alarm when the roller shutters open. How to connect a roller shutter motion detector to DoorProtect G3 Fibra...
  • Page 15 3. Ensure the hub is on and has Internet access via Ethernet and/or mobile network. You can do this in the Ajax app. 4. Check the hub status in the Ajax app. Make sure the hub is disarmed and does not start updates.

  • Page 16: Functionality Testing

    (100 for Hub Hybrid) has already been added to the hub, you will receive an error noti cation while adding. DoorProtect G3 Fibra only works with one hub. The detector stops exchanging data with the previous hub when pairing with a new one. When DoorProtect G3 Fibra is added to a new hub, it remains in the list of devices on the previous hub.
  • Page 17 The primary detector is faulty. Magnetic masking detection is disabled. Accelerometer is faulty. Magnetic masking sensor is faulty. Icons The icons display some DoorProtect G3 Fibra states. You can check them in the Ajax apps on the Devices tab. Icon Meaning Fibra Signal Strength —...
  • Page 18 DoorProtect G3 Fibra has been deactivated due to exceeding the preset number of alarms. Learn more DoorProtect G3 Fibra is deactivated for a time the armed mode is active. Learn more DoorProtect G3 Fibra has tamper triggering events deactivated for a time the armed mode is active.
  • Page 19 1°C. You can create a scenario by temperature to control automation devices. Learn more Signal strength between the hub and DoorProtect G3 Fibra. Recommended values: 2–3 bars. Fibra is a protocol for transmitting events and Fibra Signal Strength alarms.
  • Page 20 Primary Detector Open — primary contact is open. Closed — primary contact is closed. The status of the third-party detector connected to DoorProtect G3 Fibra: Disabled — the external contact is disabled (the option is disabled in the app). External Contact Open —...
  • Page 21 By number of alarms — the device is automatically excluded from the system when the number of alarms is exceeded. The number of alarms is speci ed in the Devices Auto Deactivation settings in Ajax PRO-app.
  • Page 22 Learn more Shows the status of the device one-time deactivation setting: No — the device operates in the normal mode. Lid only — noti cations on the tamper One-Time Deactivation triggering are disabled for a time the armed mode is active.  ...
  • Page 23 The number of the hub’s Fibra ring to which the Ring No. device is connected. Displayed in case of Ring connection.   Settings To change DoorProtect G3 Fibra settings in the Ajax apps: 1. Go to the Devices tab. 2. Select DoorProtect G3 Fibra from the list.
  • Page 24 Name text eld. The name can contain up to 12 Cyrillic characters or up to 24 Latin characters. Selection of the DoorProtect G3 Fibra virtual room. Room The room name is displayed in the text of SMS and noti cations in the events feed.
  • Page 25 Selecting the type of a third-party wired detector connected to DoorProtect G3 Fibra terminals: External Contact — any third-party detector External Contact Type with NC (normally closed) contact. Roller Shutter — roller shutter motion detector. The time for which the speci ed number of impulses should be counted: 5 to 30 seconds.
  • Page 26 doesn’t react to shock in 5 cases out of 5 during the test, the sensitivity should be increased. When this option is enabled, the alarm is Ignore Simple Impact activated only if the sensor detects more than one shock. When this option is enabled, the device detects Tilt Sensor a change in the tilt angle.
  • Page 27 If active, added to the system are activated when the roller shutter detector connected to DoorProtect G3 Fibra is disabled. If roller shutter is disconnected This setting is displayed if the type of external contact is Roller Shutter. sirens...
  • Page 28 the Follower is triggered individually, it immediately raises the alarm. Selecting delay time when entering: 5 to 120 seconds. Delay when entering (alarm activation delay) is the time the user has to disarm the security Delay When Entering, sec system after entering the premises. Learn more Selecting delay time when leaving: 5 to 120 seconds.
  • Page 29 Calibration of Masking Sensor Learn more Opens the DoorProtect G3 Fibra user manual in User Guide the Ajax app. Permanent Deactivation Allows the user to disable events of the device without removing it from the system.
  • Page 30 exceeded or when the recovery timer expires. Learn more Allows the user to disable events of the device until the rst disarm. Three options are available: No — the device operates in the normal mode. Lid only — noti cations on the tamper One-Time Deactivation triggering are disabled until the rst disarm.
  • Page 31 To start calibrating the masking sensor, in the Ajax app: 1. Go to the Devices tab. 2. Select DoorProtect G3 Fibra from the list. 3. Go to the calibration by clicking on in front of the Magnetic masking sensor requires calibration state.

  • Page 32: Maintenance

    Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Ajax Technical Support rst. In most cases, technical di culties can be resolved remotely.
