DoorProtect Plus User Manual
Updated October 18, 2019
DoorProtect Plus is a wireless security device which detects opening,
shocks, and tilting. It has a socket for connecting an external detector.
DoorProtect Plus is connected to the Ajax security system via the
protected
protocol, with an effective communication range of up to
Jeweller
1,200 meters without obstacles. Can operate up to 5 years from a pre-
installed battery and is furnished with a sealed contact reed relay
processing more than one million openings. It has a socket for connecting
an external detector.
Sealed contact reed relay is a device which forms a continuous circuit under the effect of a
constant magnet. It consists of ferromagnetic contacts placed in a bulb.
The detector is set up via a
for iOS and Android-based
mobile application
smartphones. The user is notified of all events through push notifications,
SMS messages and calls (if activated).
Not compatible with the uartBridge or ocBridge Plus
The Ajax security system is self-sustaining, but the user can connect it to
the central monitoring station of a private security company.
Buy opening detector with shock and tilt sensor DoorProtect Plus

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DoorProtect Plus and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX DoorProtect Plus

Summary of Contents for AJAX DoorProtect Plus

  • Page 1 SMS messages and calls (if activated). Not compatible with the uartBridge or ocBridge Plus The Ajax security system is self-sustaining, but the user can connect it to the central monitoring station of a private security company. Buy opening detector with shock and tilt sensor DoorProtect Plus...

  • Page 2: Functional Elements

    6. External detector connection socket 7. QR code 8. Device switch 9. Tamper button DoorProtect Plus Operating Principle DoorProtect Plus consists of the detector with a sealed contact reed relay, and a constant magnet. The detector is equipped with two magnets – small...
  • Page 3 (without magnets) and disable the magnetic sensor in the settings. Tilt detector detects the vertical deviation of the device relative to the initial position of more than 5°. DoorProtect Plus can be installed on windows including dormer windows, and the system can be armed, when they are in the airing mode (you should рreviously disable the magnetic sensor in the...
  • Page 4 4. Ensure that the hub is disarmed and does not start updates by checking its status in the mobile application. Only users with administrative privileges can add the device to the hub How to connect the detector to the hub 1. Select the Add Device option in the Ajax application.
  • Page 5 2. Name the device, scan/write manually the QR Code (located on the body and packaging), and select the location room. 3. Select Add — the countdown will begin. 4. Switch on the device.
  • Page 6 Request for connection to the hub is transmitted for a short time at the time of switching on the device. If connection to the Ajax hub failed (LED blinks once per second), switch off the detector for 5 seconds and repeat the attempt.
  • Page 8 Delay time when exiting Connection Connection status between the hub and the detector Primary Detector Primary detector status Secondary detector Status of the external detector connected to DoorProtect Plus Always active If active, the detector is always in the armed mode...

  • Page 9: Setting Up The Detector

    Shock sensor If active, DoorProtect Plus will detect the shock Tilt sensor If active, DoorProtect Plus will detect tilt angle changing Firmware Detector firmware version Device ID Device identifier Setting Up the Detector 1. Devices 2. DoorProtect Plus 3. Settings...
  • Page 11 Selecting the virtual room to which the device is assigned If active, the detector will switch to armed mode when using Arm in night mode night mode If active, the DoorProtect Plus primary detector reacts to Primary Detector opening/closing External contact enabled...

  • Page 12: Performance Testing

    Battery Replacement paragraph Performance testing The Ajax security system allows conducting tests for checking the functionality of connected devices. The tests do not start straight away but within a period of 36 seconds when using the standard settings. The test time start depends on the settings of...
  • Page 13 Detection Area Test Attenuation Test Selection of the Detector Location Location of the DoorProtect Plus detector determines its remoteness from the hub and presence of any obstacles between the devices hindering the radio signal transmission: walls, interfloor bridgings, large-size objects located within the room.

  • Page 14: Detector Testing

    The distance between the magnet and detector should not exceed 1 cm. When positioning the parts of DoorProtect Plus in the same plane, use the big magnet. Its actuation threshold – 2 cm.
  • Page 15 We recommend to install the wire detector at a distance not exceeding 1 meter – increasing the wire length will increase the risk of its damage and reduce the quality of communication between the detectors. To lead out the wire from the detector body, break out the plug: If the external detector is actuated, you will receive the respective notice.

  • Page 16: Installation Of The Detector

    The double-sided adhesive tape may be only used for temporary attachment of the detector and magnet. The tape will run dry in course of time, which may result in falling of DoorProtect Plus and actuation of the security system. Furthermore, the device may fail from a hit.

  • Page 17: Tech Specs

    Detector Maintenance and Battery Replacement Check the operational capability of the DoorProtect Plus detector on a regular basis. Clean the detector body from dust, spider web and other contaminations as they appear. Use soft dry napkin suitable for equipment maintenance.
  • Page 18 Tamper protection Frequency band 868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale Compatibility Operates only with Hub, Plus, Hub 2 Maximum RF output power Up to 20 mW Modulation of the radio signal GFSK Radio signal range Up to 1,200 m (any obstacles absent)

  • Page 19: Complete Set

    7. Installation kit 8. Quick Start Guide Warranty Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed battery. If the device does not work correctly, you should first contact the support service—in half of the cases, technical issues can be solved remotely!
