GlassProtect S Jeweler ist ein kabelloser Glasbruchmelder für den
Innenbereich, der das Geräusch von splitterndem Glas in einer Entfernung von
bis zu 9 Metern erkennt.
GlassProtect S arbeitet im Ajax-System und ist über das geschützte
Protokoll mit einem Hub
Hindernisse beträgt bis zu 1.000 Meter. GlassProtect S funktioniert mit einer
vorinstallierten Batterie bis zu 7 Jahre und verfügt über eine Buchse zum
Anschluss eines kabelgebundenen Detektors eines Drittanbieters. Das Gerät ist
nur für den Innenbereich bestimmt.
Diese Produktlinie wird für Projekte entwickelt. Nur akkreditierte Ajax Systems-Partner
können Superior-Produkte installieren und verwalten.
Die Produktlinien Superior, Fibra und Baseline sind untereinander kompatibel. Dies
eröffnet zahlreiche Möglichkeiten für den Aufbau beliebig kon gurierter Systeme.
GlassProtect S Jeweler
Bedienungsanleitung
Aktualisiert3. Juli 2023
verbunden . Die Kommunikationsreichweite ohne
Jeweler-
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AJAX GlassProtect S Jeweler
Summary of Contents for AJAX GlassProtect S Jeweler
- Page 1 GlassProtect S Jeweler Bedienungsanleitung Aktualisiert3. Juli 2023 GlassProtect S Jeweler ist ein kabelloser Glasbruchmelder für den Innenbereich, der das Geräusch von splitterndem Glas in einer Entfernung von bis zu 9 Metern erkennt. GlassProtect S arbeitet im Ajax-System und ist über das geschützte...
- Page 2 . Triggered when there is an attempt to tear the detector off the surface or remove it from the mounting panel. 8. QR code with the device ID. It is used to pair the device with an Ajax hub. 9. Holding screw to secure the detector on SmartBracket.
- Page 3 Hub Plus Hub 2 (2G) ReX 2 Hub 2 (4G) Hub 2 Plus Hub Hybrid (2G) Hub Hybrid (4G) Operating Principle GlassProtect S Jeweller is a wireless glass break detector. It responds to glass breaking using a built-in electret microphone. The detectorʼs microphone using the DualTone digital algorithm, only responds to sound vibrations characteristic of the sound of glass breaking, cutting off false alarms.
- Page 4 The addressability of Ajax devices allows sending events to the PRO Desktop or the CMS, the type of the device, its name, security group, and virtual room. The list of transmitted parameters may differ depending on the type of CMS and the selected communication protocol.
- Page 5 The hub and the device operating at different radio frequencies are incompatible. The radio-frequency range of the device may vary by region. We recommend purchasing and using Ajax devices in the same region. You can check the range of operating radio frequencies with the...
- Page 6 When added to a new hub, the detector is not removed from the device list of the old hub. This must be done through the Ajax app. For successful detection and pairing, ensure the detector is located within the coverage area of the hub’s wireless network (at a single protected site).
- Page 7 No connection with the hub or radio signal range extender via Jeweller. The detector battery is low. Icons The icons display some GlassProtect S states. To access them: 1. Sign in to the Ajax app 2. Select the hub. 3. Go to the Devices tab. Icon Meaning Jeweller signal strength.
- Page 8 GlassProtect S is deactivated until the rst disarm. Learn more GlassProtect S has tamper triggering events temporarily deactivated. Learn more States The States screen contains information about the device and its current parameters. Find GlassProtect S states in the Ajax app:...
- Page 9 1. Go to the Devices tab. 2. Select GlassProtect S from the list. Parameter Meaning Clicking on opens the list of the detector’s malfunctions. Malfunction The eld is displayed only if a malfunction is detected. Detector temperature. Acceptable error between the value in the app and the room temperature —...
- Page 10 How battery charge is displayed in Ajax apps Tamper is triggered if someone tries to detach the device from the surface or damage the enclosure. There are two states: Open — the detector was removed from the SmartBracket, or its integrity was compromised.
- Page 11 device does not execute system commands and does not report alarms or other events. By number of alarms — the device is automatically disabled when the preset number of alarms is exceeded (speci ed in Devices Auto Deactivation settings). Learn more Shows the status of the device one-time deactivation setting: No —...
- Page 12 Delay when entering (alarm activation delay) is the time the user has to disarm the security system after entering the premises. Delays only affect the third-party detector. Learn more Selecting delay time when leaving: 5 to 120 seconds. Delay when leaving is the time the user has to leave the premises after arming.
- Page 13 Device No. Number of the device loop (zone). Settings To change GlassProtect S Jeweller settings in the Ajax app: 1. Go to the Devices tab. 2. Select GlassProtect S from the list. 3. Go to Settings by clicking on the 4.
- Page 14 Selecting the sensitivity level of the microphone: Normal Sensitivity High The sensitivity level is selected based on the detection zone test results of the If active, GlassProtect S registers external External contact detector alarms. If the option is active, the detector is always in armed mode and noti es about alarms.
- Page 15 Selecting delay time when entering. Delay when entering (alarm activation delay) is the time you have to disarm the security system after entering the room. Delay When Entering, sec Delays only affect the third-party detector. Learn more Selecting the delay time when exiting. Delay when exiting (alarm activation delay) is the time you have to exit the room after arming the security system.
- Page 16 Switches the detector to the signal fade test mode (available in detectors with rmware version 3.50 and later). Signal Attenuation Test Learn more Opens GlassProtect S user manual in the Ajax User Guide app. Allows the user to disconnect the device without removing it from the system.
- Page 17 GlassProtect S and that the External contact option is enabled in the GlassProtect S settings in the Ajax app. Chime is a sound signal that indicates the triggering of the opening detectors when the system is disarmed.
- Page 18 Functionality testing The Ajax system offers several tests to help select the device installation place. Tests do not start immediately. However, the waiting time does not exceed the duration of one “hub—device” polling interval. The polling interval can be checked and con gured at hub settings (Hub →...
- Page 19 a metal object. After recognizing the sound, the detector switches off the LED indicator for a second. GlassProtect S does not react to clapping. To be triggered when the system is armed, the detector needs to recognize sounds in the following order: low-frequency sound (hit) rst, then high-frequency sound (glass shattering, shards).
- Page 20 Signal strength The Jeweller signal strength is determined by the number of undelivered or corrupted data packages over a certain period. The icon on the Devices tab indicates the signal strength: Three bars — excellent signal strength. Two bars — good signal strength. One bar —...
- Page 21 2. Close to sirens and speakers. This can lead to false alarms of the break detector. 3. In places with fast air circulation — for example, near fans, open windows, or doors. This can lead to false alarms of the break detector. 4.
- Page 22 If the LED indicator doesn’t light up while placing the detector on SmartBracket, check the tamper status in the Ajax app, the integrity of the fastening, and the tightness of the detector xation on the panel.
- Page 23 A wired detector with an NC (normally closed) contact type can be connected to GlassProtect S using the in-built terminal clamp. We recommend installing the wired detector at a distance no longer than 1 meter to GlassProtect S. Using a longer wire increases the risk of damage and diminishes the communication quality between the detectors.
- Page 24 Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase and does not apply to the pre- installed battery. If the device does not work correctly, you should rst contact the support service —...
