TECHNICAL SPECIFICATIONS
Technical Specifications
FREQUENCY RESPONSE
DYNAMIC RANGE
SYSTEM
SPECIFICATIONS
POWER REQUIREMENTS
(alternative or redundant)
MICROPHONE TYPE (Headset)
MICROPHONE INPUT IMPEDANCE
PREAMPLIFIER
NOMINAL / MAXIMUM LEVEL
PHANTOM VOLTAGE
IMPEDANCE
MAXIMUM LEVEL
HEADPHONE
OUTPUT POWER
AMPLIFIER
FREQUENCY RESPONSE
RESIDUAL NOISE
RATED POWER
SPEAKER AMPLIFIER
MAX SPL LEVEL
FREQUENCY RESPONSE
NOMINAL LEVEL
INTERNAL
MICROPHONE
POLAR TYPE / CHARACTERISTICS
100/1000-Mbit/s Ethernet
ETHERNET PORT
PoE compatible
RECOMMENDED CABLE TYPE
ETHERNET CABLE
Maximum recommended cable length
BLUETOOTH PORT
Bluetooth headset connection
ACCESSORIES
Headset
(optional)
AC/DC adapter
DIMENSIONS
Longitudinal measures
WEIGHT
Net without accessories
Temperature (operating)
ENVIRONMENTAL
CONDITIONS
Humidity (operating)
ALTAIR IPcom Series: Model IPB-306
TECHNICAL SPECIFICATIONS
Not e : Specifications subject to change without notice.
100 Hz – 12/24 KHz (-3 dB)
80 dB
● +24V / 90 mA nominal. AC/DC adapter
● PoE class 3 / 2.7 W
Dynamic (D) or Electret (E). Automatic Selection
4K7
-40 dBu (D) / -20 dBu(E)
+9 VDC (Automatic Selection)
200 ohm (nominal); 2K ohm (maximum).
20 Vpp (200 ohm).
250 mW (200 ohm).
250 Hz – 15 KHz.
-80 dBu (all mics off)
0,5 WATIOS @ 8 ohm
85 dB SPL @ 0,5m
250Hz-5KHz
-50 dBu
Electret / Directional
IEEE802.3-2002 standard
IEEE802.af standard
CAT. 5E or superior (1000BASE-T)
100m
2.4 GHz frequency. Bluetooth® standard
ALTAIR AM100 Series
REF: VET-24
90×50×150 mm(LxAxP)
250 gr
0ºC a 50ºC
10% a 90% (HR, no condensed)
